Outline
Two channels IP output multiplexer is an enhanced TS re-multiplexer for digital TV broadcasting head-end system. The multiplexer has all the functions of normal TS multiplexer, including programs multiplexing, PSI/SI editing, PID re-mapping, service filtering etc. The multiplexer can insert EPG (Electronic Program Guide), CA (Conditional Access) and data casting information into each output stream. Different from normal multiplexer, this multiplexer has eight ASI inputs (DVB/C/S/S2/T optional), two separate ASI output ports and two separate megabit IP outputs. The bit rate of output stream can be up to 216Mbps. For the application area, this device is especially applicable to the FTA (Free to Air) system multiplexing.
Features
-
Fully complying with ISO13818 and EN300 468 standard
-
Integrated demodulating and multiplexing functions
-
8 ASI(DVB/C/S/S2/T optional)inputs
-
MPEG-2 transport stream re-multiplexing
-
SPTS and MPTS code stream multiplexing
-
PCR correcting and PID re-mapping
-
Two groups of separate TS outputs (each group has 2 channels)
-
Two IP outputs (the copies of 2 ASI outputs)
-
PSI/SI editing
-
Huge buffer memory for saving the overflowing code stream
-
Supporting to multiplex one program to all outputs
-
Alarming function
-
Network long-distance upgraded
-
With high reliability design and stability operation
-
Full keyboard operation and LCD display
-
Network management system
Specifications
|
Input interface |
ASI |
8 ASI inputs (DVB/C/S/S2/T optional) (Up to 214Mbps per channel) |
|
Re-multiplex |
MPEG-2 TS re-multiplex |
|
|
PID re-mapping ( auto/manual optional) |
||
|
PCR correction |
||
|
Automatic generating PSI/SI table |
||
|
Input |
Packet format |
204/188 self-adaption |
|
Output port |
ASI |
2 groups of separate outputs (each group has 2 channels) |
|
IP |
2 channels of separate IP outputs (share one 100M Ethernet port) |
|
|
PID |
Output range |
0000—1FFF |
|
PID transparent |
Any PID transparent and mapping achievable |
|
|
Amount of output PID per input |
256 |
|
|
NMS port |
Ethernet port |
10/100M |
|
General |
Demission (W x L x H) |
482mm×410mm×44mm |
|
Weight |
6kg |
|
|
Temperature |
0~45℃(operation),-20~80℃(storage) |
|
|
Power supply |
AC 110V±10%,50/60Hz Or AC 220V±10%,50/60Hz |
|
|
Consumption |
18W |
|
System Structure Chart
