Name:
Expendable Thermocouple Head
Thermocouple tip/head are used for measurement of molten metal temperatures.
Instrument:
Thermocouple tip has two type.
Type:QR-KW/S/R/B-602J Type:QR-KW/S/R/B-604J
( The letter J stand for the exact thermocoupl wire and the tolerance is no more than 2°c).
Thermocouple wire:
Thermocouple tip:
| Type | Model | Max.Temperature |
| Type WRe(W25%Re-W3%Re) | QR-KW-602/604 | 1820°c |
|
Type S ( Pt-Pt10%Rh) |
QR-KS-602/604 | 1760°c |
| Type R (Pt-Pt13%Rh) | QR-KR-602/604 | 1760°c |
| Type B (Pt6%Rh-Pt30%Rh) | QR-KB-602/604 | 1800°c |
We have two type of thermocouople tips,the shape of tip bottom is round,which we called type 602 thermocouple tip.The other shape of tip bottom is triangle,which we called type 604.
According to the different way of connection,thermocouple connector has two types are 602 connector and 604 connector.
This is 602 thermocouple tip and 602 connector
This is 604 thermocouple type and 604 connector
Advantages:
(1)high accuracy,rapid reaction,reliablity and stablility.
(2)Excellent precision with 5c for the tolerance.
(3)Reaction time quikly,reaction time≤5s.
(4)High temperature limit,hight temperature:1800degrees celsius
