Antistatic Thread For Conductive Clothing

Specifications

Antistatic Thread For Conductive Clothing manufactuer
OEM,ODM available
SGS certificate
use for electric shock



1.conductive thread  /Antistatic Thread For Conductive Clothing









Description:filament conductive thread   has consisted of forever and non-forever series, our company only produce forever series.



1.Conductive thread   Products description :



As we all know the clothes,shoes ,hat ,fabric can build up static,but some special place cann’t build static,such as : Anti-static workshop and Clean Room.So our company have research anti-static yarn meet these requirements.



2.Conductive thread Principle:



filament conductive thread yarn  is made by inserting anti-static fiber in sewing thread. Its resistivity is above 10⁶. ohmic resistance is less then 20 ohm,So that is why it can be functioning of anti-static .



3.filament conductive thread yarn  Spec.



We have 20# 420D/3,30# 300D/3,40# 210D/3,60# 150D/3,20S ,30S/1 etc.Normally, specification 60# is used in anti-static uniforms.



4.The style of filament conductive thread yarn





1).carbon fiber+fliament polyester thread

2).carbon fiber+nylon thread

3).spun stainless steel staple +100%cotton yarn

4).filament stainless steel stape +filament polyester thread

5).Copper fiber +nylon yarn

 6). silvered fiber+polyster yarn

 7). 80% combed polyester 20% stainless steel staple fiber





5. Conductive thread Color/Antistatic Thread For Conductive Clothing



Both anti-static thread and conductive thread are made by two different fibers. Though, this type of thread can be dyed, its dye effect is not as good as those made by the same fiber.(as follow is filament counductive thread dyed yellow colors)







 6. Conductive thread /Antistatic Thread For Conductive Clothing  Application:









7.Antistatic Thread For Conductive Clothing Packing and other details



Carton size for95g:56*29.5*12CM=0.02M3   (50 cones/carton)

Carton size for 95g:45.5*30.5*28.5CM=0.04M3   (80 cones /carton)



8.Our  certificate :



Factory showing :







10.Our other series products:
