160X120 Pengimejan Terma UTI160A

Name: 160X120 Pengimejan Terma UTI160A
Brand: UNI-T
SKU: 146820698
Availability: InStock

Bestern- Asia Industrial Limited

US$ 2656 - 2656 MOQ: 1 Piece

Key Specifications

Brand Name:

UNI-T

Place of Origin:

China

Model Number:

UTI160A

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name UNI-T

Place of Origin China

Model Number UTI160A

Infrared Thermal Imager UTI160A

SPECIFICATIONS	UTI160A
Imaging Performance
Thermal field of view	20°x15° 6.4°x4.8° 12°x8°
Spatial resolution	2.20 mRad
Minium Focus Distance	0.1m
Thermal Sensitivity (NETD)	0.08°C @ 30 °C
Detector Data Acquisition	60Hz
Focus	Manual
Detector type	UFPA,160X120
Spectral band	8~14 um
TemperatureMeasurement
Range 1	-20°C to 250°C
Range 2	200 °C to 1000 °C
Range 3	800 °C to 1500 °C
Accuracy	±2 °C or 2%
Temperature alarm	Max/min
Correction	Emissivity (0.1 to 1.0,0.01 increments), ambient temp., distance, relative humidity
Image Presentation
Digital Display	2.5" LCD
LCD backlight	CCFL
Video output	NTSC 60Hz / PAL 50 Hz composite video
Pallettes	6
Image and Data Storage
Storage Medium	MinIR SD card/2GB
File format	14 bit measurement data included, SAT format
Interfaces and Software	MinIReport
Power, Battery Life
Battery type	Rechargable Lithium Battery
Battery operating time	2.5 Hours continous
Battery charging	1 bay intelligent charger powered via AC outlet
Power saving	Automatic shut down and sleep mode
Environmental and mechanical design
Operating temparature	Negative 15 to 50 C
Storage temparature	Negative 40 to 70 C
Rrelative humidity	10% to 95%, non-condensing
Water and dust resistant	IP54
Shock	Operational: 25G
Vibration	Operational: 2G
Weight (battery included)	500g
Size	172mm x80mm x 162mm
Tripod mounting	1/4"_20
