Semiautomatic Soldering Machine C9 With Solder Feeder

Name: Semiautomatic Soldering Machine C9 With Solder Feeder
Brand: SMARTER
SKU: 146813216
Availability: InStock

Shen Zhen SMARTER Automation Equipment Co., Ltd

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

SMARTER

Place of Origin:

China

Model Number:

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name SMARTER

Place of Origin China

Model Number C9

Delivery Time:Within 2 days upon receipt of payment
Certification:CE certificated

Specification ：

Out put voltage	AC110V 60Hz/AC220V 50Hz
Consumption power	95W
solder feeder speed	3.00mm/s-30.00mm/s
solder back time	0.00s-61.00s
Temperature stability	±1℃（No load）
Sleeping time	1-60min（0 no sleeping）
Sleeping temp.range	50℃-below the set temp
Display	LCD
The potential between tips and grounding	Below 2mV
Outline dimension	430（D）123（W）170（H）mm
Heater power	AC24V 80W
Motor power	DC24 65mV
solder feeder time	0.00s-65.00s
Transport model	Auto/Manual
Temp. range	150-450℃
Password set range	001-999（000 no password）
Manual temperature adjustment range	-50℃-50℃
Solder Dia	0.5/0.6/0.8/1.0/1.2/1.5/1.6mm （Different solder wire match with different tube）
The resistance between tips and grounding	Below 2Ω
Net weight	5Kg

Function & Features / Choice basis：

	Fixed the soldering tips on the machine, it can feeder soldering to the head of the soldering tips automatically(no need one hand with solder, anther hand hold solder handle)so this permit operator hold the solder equipment with two hands

	Footswitch control solder feeder

	Two ways of soldering feeding a, Auto soldering feeder:open the machine, fixed solder wire length, cycle operation b, Manual soldering feeding:press the switch to feeder solder, loose switch to stop solder feeding

	Freely set solder feeding length(under Auto model, achieved by setting solder feeding time)

	Freely set soldering feeding speed, quick or slow as requirmennt

	Feeding solder position can rotate to aleatoric angle 360 C of the solder tip

	Nose(soldering tips)angle adjustable
Solder anti-splash function Punch cut on the solder can decrease the splash during soldering. Note: solder tu
