High Quality 30W LED High Bay Light Fixtures QH-IL-30W1A

30W LED Industrial Light Main Technical Parameters

1

Item No.:

QH-IL-30W1A

2

Input Voltage:

AC100~240

3

LED Consumption:

30W

4

LED QTY:

1pc*30W

5

LED Working Voltage:

DC 30~36V

6

System Consumption:

36 W

7

LED Luminous Flux

Warm White

2400LM

Pure White

2700LM

Cool White

2700LM

8

Lamp's Efficiency

75%

9

Viewing Angle:

45 degree

10

Average Illuminance

Height 6M

84 LUX

Height 8M

46.8 LUX

Height 10M

30 LUX

11

Color Temperature

Warm White

2700K~3500K

Pure White

5000K~5500K

Cool White

6000K~7000K

12

Color Rendering Index

Warm White

Ra≥68

PW, CW

Ra≥75

13

Working Temperature:

–40ºC~50ºC

14

IP Grade:

IP65

15

Working Life-span:

50000 H

16

Connect Wire

Brown

L

Blue

N

Yellow/Green

G

17

The color of the lamp shell

Black and Silver is available

18

Certificate

CE, FCC, TUV, UL
