Stainless Steel Wire Cloth Netting

Name: Stainless Steel Wire Cloth Netting
Brand: Haitong
SKU: 146743554
Availability: InStock

Anping Haitong Metal Products Co.,Ltd

US$ 5 - 5 MOQ: 100 Sets

Key Specifications

Brand Name:

Haitong

Place of Origin:

China

Model Number:

HTWS

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name Haitong

Place of Origin China

Model Number HTWS

Specification of Stainless Steel Wire Mesh (Wire Cloth), Plain Weave
mesh/inch	wire diameter mm	aperture mm		mesh/inch	wire diameter mm	aperture mm
2mesh	1.80	10.90	60mesh	0.15	0.273
3mesh	1.60	6.866	70mesh	0.14	0.223
4mesh	1.20	5.15	80mesh	0.12	0.198
5mesh	0.91	4.17	90mesh	0.11	0.172
6mesh	0.80	3.433	100mesh	0.10	0.154
8mesh	0.60	2.575	120mesh	0.08	0.132
10mesh	0.55	1.990	140mesh	0.07	0.111
12mesh	0.50	1.616	150mesh	0.065	0.104
14mesh	0.45	1.362	160mesh	0.065	0.094
16mesh	0.40	1.188	180mesh	0.053	0.088
18mesh	0.35	1.060	200mesh	0.053	0.074
20mesh	0.30	0.970	250mesh	0.04	0.061
26mesh	0.28	0.696	300mesh	0.035	0.049
30mesh	0.25	0.596	325mesh	0.03	0.048
40mesh	0.21	0.425	350mesh	0.03	0.042
50mesh	0.19	0.318	400mesh	0.25	0.0385
Electric Welding Net: 0.6m-1.5m

Specification of Stainless Steel Wire Mesh( Wire Cloth), Twill Weave
Mesh	Wire Dia.(mm)	Opening(mm)	Material(AISI)
250mesh	wire dia.0.040mm	0.063	304 or 316
300mesh	wire dia.0.040mm	0.044	304 or 316
325mesh	wire dia.0.035mm	0.043	304 or 316
350mesh	wire dia.0.030mm	0.042	304 or 316
400mesh	wire dia.0.030mm	0.033	304 or 316

Specification of Stainless Steel Wire Mesh ( Wire Cloth), Dutch Weave
Mesh x Mesh	Wire Dia.x Wire Dia.	Material
24mesh x 110mesh	0.35mm wire dia.x 0.25mm wire dia.	AISI 304/316
30mesh x 150mesh	0.23mm wire dia.x 0.18mm wire dia.	AISI 304/316
50mesh x 600mesh	0.18mm wire dia.x 0.11mm wire dia.	AISI 304/316
20mesh x 200mesh	0.75mm wire dia.x0.21mm wire dia.	AISI 304/316
50mesh x 250mesh	0.14mm wire dia.x 0.11mm wire dia.	AISI 304/316
20mesh x 250mesh	0.25mm wire dia.x 0.20mm wire dia.	AISI 304/316
30mesh x 360mesh	0.23mm wire dia. x 0.15mm wire dia.	AISI 304/316
12mesh x 120mesh	0.35mm wire dia. x 0.224mm wire dia.	AISI 304/316
20mesh x 80mesh	0.45mm wire dia. x 0.35mm wire dia.	AISI 304/316
80mesh x 700mesh	0.06mm wire dia. x 0.05mm wire dia.	AISI 304/316
165mesh x 800mesh	0.071mm wire dia.x 0.045mm wire dia.	AISI 304/316
165mesh x 1400mesh	0.071mm wire dia.x0.04mm wire dia.	AISI 304/316
200mesh x 1800mesh	0.05mm wire dia.x0.032mm wire dia.	AISI 304/316
