The Roller reamer is designed for any reaming operation and particularly for stabilization purposes when drilling in abrasive formations. According to the different hardnesses of formations,you may separately select sharp-fanged roller,wide-fanged roller or tungsten carbide compacts roller. In addition, each body, by simple adjustment of blocks and proper selection of cutters, will suit a wide range of hole sizes.
MDX Roller Reamers have a heavy duty design based on a wide range of operating experience. They can drill in any condition, be it soft, medium or hard formations. The reamers are built to maintain the necessary hole gauge when drilling straight or deviated holes. They consist of cutter, bearing pin, cross pin, lower block, upper block, secondary locking bolt.
Its simple design allows for complete cutter replacement at the rig site, without welding or the need of special tools.Three and six point roller reamers are available with a lubricated and sealed cutter assembly.
Pressure balanced sealed journal bearing assembly has a long service life.
Three different types (T, F and B) of rollers are offered.
Type T: narrow tooth is machined and surface hardened, which is used for cutting of hole wall, used for soft formation. (Roller Cutter: like soft lime and shale. Hardened, carburized, quenched and tempered teeth）
Type F: wide flat tooth is machined and surface hardened, which is used for cutting and crushing of hole wall, used for medium hard formations (Chert: for medium to medium-hard formations, like dolomite, hard lime and chert, where crushing action is required.)
Type B: the roller is cold inserted with tungsten carbide string or Equipped with pressed-in tungsten carbide buttons, for hard formations. (Knobby: for hard ,extra-hard, abrasive and semi-abrasive formations, like sand or granite.)
Ordering information:
To order for request cost information on MDX Roller Reamer assemblies, please specify:
l Three or six point configuration.
l String or near bit.
l Roller cutter type.
l Drill collar (fishing neck and long space ) diameter.
l Size and type of upper and lower connections
l Hole size.
