Help CenterLow Voltage, Low Maintenance Smd Led Tube Light
Related Products
-
33W T10 Led Lights With Led Lights ManufacturerUS$ 71.6 - 71.6MOQ: 50 Units -
3years Warranty Lowest CO2/t8 Smd 25w AC85-265V Input Voltage t8 Led Tube Light, t8 Led Tube Light WholesalersUS$ 14.6 - 14.6MOQ: 50 Units
-
3w 311mm High Quality Tubes FluorescentUS$ 3.2 - 3.2MOQ: 25 Units
-
LED Tube Light 2400mm 8feet CE. PSE, C-TICK ApprovalUS$ 66 - 66MOQ: 25 Units
-
18W SMD5050 T8 LED Tube Light High LumenUS$ 36 - 36MOQ: 25 Units
a. smd led tube light material: Aluminum alloy + PC (Transparent PC, Frosted PC and Strip PC available)
b. Light source: super brightness Dip or SMD (3528) LED;
c. Chip brand: Epistar (made in Taiwan)
d. Span life: 50000 to 80000 hours.
e. Input voltage: AC85V-265V
f. Above 70% Energy saving, almost no maintenance, without starter and ballast, fast starting, no flashing.
2. smd led tube light installment and attention
1. According to the picture representation, install the match length bracket as the smd led tube light from the smd led tube light vertical direction.
2. Intervene the matching power wire to the one side (no positive and negative difference) of the bracket base as the picture shows, make the other side hang, then, connecting AC220V power and would be lighted.
3. The smd led tube light could not tear down the light tube only or install other brackets to lighten; it must match our company’s bracket to use.
4. This smd led tube light can’t replace the conventional T5 Fluorescent Tube.
5. This smd led tube light can be used by series after put the two smd led tube lights in the bracket. At most 50 pieces in series.
6. Don’t separate this product, it’s not in the guarantee .If any error state appears, please contact with us.
3. smd led tube light T5 specification
|
Power Factor |
Span Life |
Microwave/ |
Open Protection |
Constant Currency Error |
Light source |
|
>90% |
50000(hrs) |
<240mV |
OK |
<2% |
Super Bright LED |
|
Work Temp |
CRI |
Light Efficacy |
Static Power Consumption |
Storage Temp |
Short Circuit |
|
-20 -65℃ |
>75% |
>85% |
<0.15W |
0 -65℃ |
OK |
4. smd led tube light after-sale service
Any disorder appears under normal operating, we ensure to exchange within 7 days, 3 years guarantee, and life-long maintenance. Any man-made damage and natural disaster is not under warranty. Any query for the smd led tube light products, please kindly feel free to contact smd led tube light manufacturers of Yao Hu
