2BQ-4/2BQ-6/2BQ-8 Series Summation
It is a versatile fully linkage agricultural machine. It is suitable for drilling and fertilizing in fields that have been cultivated. By replacing with different sizes of discharging discs, users can get different spacing in the row when precisely seedering corn, soybean, sorghum, cotton(seeds are cleaned by sulphuric acid) or sunflower seeds. During one operation it can finish fertilizing, opening up ditches, planting, covering with soil and pressing. So it can perform more operations, being versatile and popular in application.
Its flute wheel fertilizing device can discharge particle fertilizers that have good fluidity, for example urea.Moreover, it can lead fertilizers deep into where the crops root is, so that the fertilizers could function to the most. What is more, its fertilizing from the side can avoid damaging the seeds.
2BQ series Precision Seeders by means of Aspiration features reasonable construction and reliable properties, it can save seeds, reduce agricultural consumption, and increase output volume, so at the moment it is an ideal agricultural machine fit for China conditions.
It drills precisely at high speed, and recombination operation results in that both seeds and labour cost are saved, it can work efficiently.
2BQ-4/2BQ-6/2BQ-8 Technical Specifications
|
MODEL NO. |
2BQ-4 |
2BQ-5 |
2BQ-6 |
2BQ-8 |
|
Overall dimensions(L*W*H)(mm) |
2300*1500*1220 |
2800*1500*1220 |
3400*1500*1220 |
4600*1800*1500 |
|
Net Weight(Kg) |
520 |
560 |
600 |
930 |
|
Driven power(Kw) |
18-22 |
18-22 |
30-37 |
48-70 |
|
Working Speed(km/h) |
5-6 |
6-7 |
7-8 |
7-8 |
|
Spaces between Rows(mm) |
460-660 |
|||
|
Type of Seeds Discharger |
Vertical Disc, by means of aspiration |
|||
|
Diameter of Discharging Discs(mm) |
200 |
|||
|
Type of Fan |
Centrifugal impeller |
|||
|
Diameter of Impeller(mm) |
328 |
|||
|
Ranges:of Spacing in the row(mm) |
22-340 |
|||
|
Volume in Discharging Fertilizer |
6-30kg/mu |
|||
|
Type of Transmission |
Sprocket and Chain |
|||
