Detailed Product Description
2.Roll speed : 15M/MIN
3.Motor power: 5.5KW
4.Cutter power : 3KW
5.Roller passes: 18 passes
The Technical Explanations of corrugated sheet cold roll forming machine
Main Technical Parameters
1. Rolling product specification : 1000mm
2. Rolling speed : 0-15m/min
3. the groups of roller : 18passes
4. the material of roller adopting : 45# steel to plate hard chrome
5. the material of principal axis high quality : 45# steel
φ70mm
6. Main motor power : 5.5 kw
7. Type of drive; chain wheel and chain drive
8. The length of main machine : 8m*1.6m*1m
9. The total weight of main machine: about 4 tons
10. hydraulic cutting system; power 3kw
The machine is driven shear cylinder mould,cut off in order to achieve results. All hydraulic components are produced by well-known manufactures.
The raw material of shear mould Cr12.
The hardness of heat treatment HRC58- 60°
