INTRODUCTIONCE-Link's HCL0101 is a HDMI extender while using CAT-5E cable as transmission media.Benefits from using HCL0101:1) The length of HDMI cable is fixed and unchangeable after it is produced. Becausethe HDMI connector can only be soldered or terminated by professional worker infactory, the users can not reduce or increase by themselves. However CAT5E cablesare available everywhere and be processed easily by the user or installer.2) When cabling in hidden method, because the header of long HDMI cable is big, andso is the cable. So it is not easy to bend the HDMI cable and pull it through thein-wall tube or tray. However, CAT-5E cable has no such problem.3) By using HCL0101, the transmission distance can up to 60 meters. For general HDMIcables, cables must be customized when the length over 10 meters.FEATURES -One pair as a full functional module, no need of setting. -Use CAT-5E cable to substitute HDMI cable to achieve long distance transmission.-Follow the standard of IEEE-568B. -Transmission distance reaches up to 60 meters.-Auto-adjustment of feedback, equalization and amplify, the user does not need tocare about the length of the cable. -Compact size.-Signaling rates up to 2.25Gbits in support of 1080P display.-Each port supports HDMI or DVI inputs. -HDCP compliant.Notice China Electronics Technology Limited reserves the right to makechanges in the hardware, packaging and any accompanyingdocumentation without prior written notice.PACKAGE CONTENTS1) Main unit NO. 1 P/N_HCL0101A2) Main unit NO. 2 P/N_HCL0101B3) 5VDC Power Supply.4) Operating Instructions. CONNECT AND OPERATE 1) Connect the HDMI input sources such as:HD-DVD,PS3,STB etc.) into P/N_HCL0101A. 2) Connect two CAT-5E cables to both the outputs of P/N_HCL0101A and inputs of P/N_HCL0101B. 3) Connect the HDMI output( such as : HD-LCD,HD-DLP)into P/N_HCL0101B. 4) Plug the power into P/N_HCL0101B.SPECIFICATIONSOperating temperature range.................-5 to +35癈(-41 to +95癋)Operating humidity range..........5 to 90 % RH (no condensation)Signalling rates...................................................2.25Gbits x 3Input Video Signal...........................................0.5-1.0 volts p-pInput DDC Signal.............................................5 volts p-p (TTL)Video format supported:...DTV/HDTV:1080P/1080i/720P/576P/480P/576i/480iOutput Video.............................................................HDMI1.3Transmission distance.....................................................60MPower Consumption................. .................120mWatts (max.)Dimensions..................................40mmW x 77mmH x15mmDMass..............................................................................63g
