Single Stud Fitting With Stainless Steel Ring Used on a Trailer to Secure Motorcycles and ATVs

Specifications

Technical Data:

A=20mm

B=56mm

C=17.5mm

D=38mm

S=5mm

Breaking Load: 1800kg

Remark: 2" Airline Fitting

 How to use:

1. Simply make sure the clip of the stud fitting runs parallel with the track.

2. Put your thumb inside the ring and push down on the "stud" while lifting the clip with your index and middle fingers. You will see a round disk has been ejected from the clip.

3. Insert this disc into the desired round cut-out of your track.

4. Slide the fitting either direction so it is halfway between two of the tracks openings and let the clip fall on both sides of the fitting in the 2 round slots on both sides of the stud.

5. Simply lift the clip and slide to adjust or remove from the track.

 Applictions:

The single stud fitting is designed to be used with L Track, sometimes called Logistic Track or Airline Track due to its popularity with the airline industry. The stud fitting features a stainless steel ring for superior strength and holding power. For even more strength and security, try some of our other L track fittings such as the double stud fitting with o-ringor the double stud fitting with pear link.
