cargo inflate air dunnage bags inflatable container dunnage bags

Specifications

1.Quick inflation;
2.Patent valve;
3.Eco-friendly material;
4.Shock protection, Excellent buffer;
5.SGS approved.





Detailed images













Detailed specification





Model	Air Bag Size                 (W×L)mm	Void width≤(mm)	Height(mm)
YLDB0510A	500×1000	200	900
YLDB 0812A	800×1200	250	1100
YLDB 0918A	900×1800	250	1700
YLDB 1018A	1000×1800	300	1700
YLDB 1020A	1000×2000	300	1900
YLDB 1022A	1000×2200	300	2100
YLDB 1224A	1200×2400	400	2000
Working pressure: 0.1Bar/10Kpa/1.45P.S.I







Advantages & application



1. consists of one layer high strength Kraft paper(100g/m2) outer and a polyethylene inner(thickness 0.1mm)

2. industrial style spring valve(one way) to handle the toughest rides

3. moisture resistant & high burst pressure

4. superior cushioning effect. It can absorb and release external force and vibration.

5. high quality cushion, improve company image for its good protection of goods.

6. It remains flat before inflation, requiring minimal storage and transportation space.

7. cost effective added assurance

8. easily fast inflation process, save packing/loading time and reduce transport cost

9. recyclable and Reusable(reusable for 5 times under proper use), saving resources

10. working pressure: 0.1bar, burst pressure 0.4bar

11. ISO certified, SGS certified, conforming to ROHS regulations.

12. Application fields: during transportation of light items such as electric, IT, etc.

13. Different sizes are available for different usage conditions. popular sizes(WXL :mm):500×1000, 800×1200, 1000×1800 ,1000×2000,1000×2200







Cautious



1. In order to protect the operator when open the door of the container, do not use Dunnage bag between the goods and door of container.

    If it must use it ,please stay dunnage bag.

2. Before use the dunnage bag, measuring the overall height of the goods, the void between the goods package, the depth of the pallet package, etc.

3. Make sure the working pressure is 0.1Bbar/10Kpa/1.45P.S.I.

4. If the package with sharp edge(such as wood case, wood pallet), please input the card paper or other honey panel around the dunnage bag to

protect the dunnage bag out of puncturing.
