Slewing Bearing/turntable Bearing YRT100

slewing bearing/turntable bearing YRT100

YRT bearing YRT bearing consists of a thrust/heart to race, a thrust/to the spindle, a thrust washer, two needle cage components and a set of radial cylindrical roller. The installation of the seat ring and shaft uniform with a screw hole. This type of bearing has high axial and radial load capacity. High tilt stiffness and high precision. Apply to the rotary table, chuck and iron and the bearing measurement and experimental configuration of the cutting tools. This type of bearings for matching the requirements of the parts of the equipment is also higher. When installation should install screw tightening torque control. Mainly used in high precision nc rotary table, dividing head, military radar, aviation, aerospace, and measuring and test requirement of high precision in the field.

Due to the fixing holes in the bearing rings, the units are very easy to fit.The bearings are radially and axially preloaded after fitting.The mounting dimensions of all series are identical.

if you are interested in our products, please feel free to contact with me :)

Attn: connie

email: connie at

whatsapp:+8615073676619

wechat: empty919
