BCH2020 professional OEM closed end drawn cup needle roller bearing
Feature
Drawn cup needle roller bearings support radial loads and reduce friction between rotating components, with a drawn outer shell serving as a raceway for the rollers. The low cross section of the drawn cup bearing provides high load-carrying capability with minimum required space. Drawn cup bearings are easily installed with a press fit in the housing.
Needle roller bearings are cylindrical roller with a roller bearing, relative to its diameter, roller both thin and long. This is called needle roller. Despite having a smaller cross-section, it has a higher load bearing capacity, equipped with a thin and long needle bearing roller, so the radial structure is compact, its diameter size and load capacity and other types of bearings, the outer diameter minimum, especially for radial mounting dimensions restricted support structure.
Details
| Fw | 1 1/4 inch | |
| Fw | 31,75 mm | |
| D | 1,625 inch | |
| D | 41,275 mm | |
| C | 1,25 inch | |
| C | 31,75 mm | |
| m | 0,174 lbs | Mass |
| m | 79 g | Mass |
| Cr | 9800 lbf | Basic dynamic load rating, radial |
| Cr | 43500 N | Basic dynamic load rating, radial |
| C0r | 16400 lbf | Basic static load rating, radial |
| C0r | 73000 N | Basic static load rating, radial |
| nG | 7900 1/min | Limiting speed |
Datasheet
| Item No. | Fw(mm) | D(mm) | C(mm) | Mass(g) |
| SCH 1612 | 25.4 | 33.338 | 19.05 | 0.036 |
| SCH 1614P | 25.4 | 33.338 | 22.22 | |
| SCH 1616 | 25.4 | 33.338 | 25.4 | 0.047 |
| SCH 1812 | 28.575 | 38.1 | 19.05 | 0.048 |
| SCH 1816 | 28.575 | 38.1 | 15.4 | 0.063 |
| SCH 2016 | 31.75 | 41.28 | 25.4 | 0.071 |
| SCH 2213P | 34.925 | 44.45 | 20.62 | |
| BCH 68 | 9.525 | 15.875 | 12.7 | 0.0082 |
| BCH 06604 | 17.02 | 23.83 | 17.53 | |
| BCH 2020 | 31.75 | 41.275 | 31.75 | 0.0815 |
Contact
Attn: Emily
E-mail: emily at
Skype:Emily Cosmic
Welcome to enquire for more details!
