SCE1416 BA1416, 7/8 x 1 1/8 x 1 Inch, Needle Bearing

SCE1416 BA1416, 7/8 x 1 1/8 x 1 Inch, Needle Bearing thumbnail-1
SCE1416 BA1416, 7/8 x 1 1/8 x 1 Inch, Needle Bearing photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
NTL
Bore Size:
22.225,
Outside Diameter:
28.575,
Contact Supplier Request Quote Chat Now
Changsha Terry Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NTL
Bore Size 22.225,
Outside Diameter 28.575,
Model Number SCE1416 BA1416
Precision Rating P0
Number of Row Single Row
Place of Origin Jiangsu, China

SCE1416 BA1416, 7/8 x 1 1/8 x 1 inch, Needle Bearing





Introduction of Drawn cup needle roller bearing
1. Drawn cup roller clutches are one-way clutches comprising thin walled, drawn outer rings with a series of ramps on the inside diameter, plastic cages, pressure springs and needle rollers. They can transmit high torques in one direction and are particularly compact in a radial direction. The roller clutches are available with and without bearing arrangements.

2. Drawn cup roller clutches give very precise indexing, since the individual spring loading of the needle rollers ensures continuous contact between the shaft, needle rollers and ramps. They allow high indexing frequencies due to their low mass and the resulting low moment of inertia of the clamping elements. They also have a low overrunning frictional torque.
Application of Drawn cup needle roller bearing
Drawn cup roller clutches can be used in a wide variety of applications, for example as indexing elements, back-stopping clutches or overrunning clutches. In these cases, the drawn cup roller clutch performs an overrunning or locking function.
Drawn cup needle roller bearing SCE2110









15.875 SCE108 BCE108 15.875 20.638 12.7 8743 12015 16000
SCE1010 BCE1010 15.875 20.638 15.88 10368 16242 16000
SCE1012 BCE1012 15.875 20.638 19.05 12015 19802 16000
17.462 SCE116 BCE116 17.462 22.225 9.52 5740 7876 15000
19.05 SCE1210 BCE1210 19.05 25.4 15.88 12682 17577 13000
SCE1212 BCE1212 19.05 25.4 19.05 15352 22250 13000
20.638 SCE1312 BCE1312 20.638 26.988 19.05 16020 23585 12000
22.225 SCE148 BCE148 22.225 28.575 12.7 11125 15797 11000
SCE1412 BCE1412 22.225 28.575 19.05 16910 27145 11000
23.812 SCE1516 BCE1516 23.812 30.162 25.4 24030 43165 11000
25.4 SCE168 BCE168 25.4 31.75 12.7 12682 19135 10000
SCE1612 BCE1612 25.4 31.75 19.05 18022 30260 10000
SCE1616 BCE1616 25.4 31.75 25.4 24920 45390 10000
28.575 SCE188 BCE188 28.575 34.925 12.7 12905 20247 9000
SCE1812 BCE1812 28.575 34.925 19.05 18912 33375 9000
SCE1816 BCE1816 28.575 34.925 25.4 25810 49395 9000
31.75 SCE2012 BCE2012 31.75 38.1 19.05 21137 39605 8000
SCE2016 BCE2016 31.75 38.1 25.4 27145 54735 8000
34.925 SCE2212 BCE2212 34.925 41.275 19.05 21360 42720 7500
SCE2216 BCE2216 34.925 41.275 25.4 27590 59185 7500
38.1 SCE2416 BCE2416 38.1 47.625 25.4 38715 66305 6500
40.45 SCE2816 BCE2816 44.45 53.975 25.4 41385 75650 6000
50.8 SCE3220 BCE3220 50.8 60.325 31.75 55180 115700 5000





SCE1416 BA1416, 7/8 x 1 1/8 x 1 inch, Needle Bearing



SCE1416 BA1416, 7/8 x 1 1/8 x 1 inch, Needle Bearing



SCE1416 BA1416, 7/8 x 1 1/8 x 1 inch, Needle Bearing



If you need,just feel free to contact with us.
