Home > Industrial Equipment & Components > Bearing > Deep Groove Ball Bearing > 608ZZ Chrome Steel Deep Groove Ball Bearing for 3D Printer
US$ 0.12 - 1
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
NTL
Bore Size:
8,
Outside Diameter:
22,
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Metal Hand Spinner Toy Great Gift for ADD, ADHD, Autism Adult ChildrenUS$ 2 - 5MOQ: 1 Piece -
2017 Hotsale Rainbow Hand Fidget Spinner ToyUS$ 3 - 7MOQ: 1 Piece
-
Metal Alloy Rainbow Tri Hand Spinner Fidget Spinner With R188 BearingUS$ 4 - 6MOQ: 1 Piece
-
Ceramic Bearing 608 for Hand Spinner Fidget Finger SpinnerUS$ 0.8 - 2MOQ: 10 Pieces
-
Sealed 8mm Bore Hybrid Ceramic Si3N4 Ball BearingUS$ 1 - 3MOQ: 1 Piece
Brand Name
NTL
Bore Size
8,
Outside Diameter
22,
Model Number
608ZZ
Precision Rating
high precision
Seals Type
ZZ 2RS OPEN
Number of Row
Single Row
608 ball bearing
608ZZ Chrome steel deep groove ball bearing for 3D printer
We suppy the ceramic ball bearing ,ceramic roller bearing,ceramic insert bearing as good quality at best price,any needs,pls feel free to contact us.
| Flange | Open | Shield | Boundary Diameter | ||
| d | D | Df | |||
| F | 681 | 1 | 3 | 3.8 | |
| F | 691 | 1 | 4 | 5 | |
| F | 682 | ZZ | 2 | 5 | 6.1 |
| F | 602 | ZZ | 2 | 7 | 8.5 |
| F | 603 | ZZ | 3 | 9 | 10.5 |
| F | 623 | ZZ | 3 | 10 | 11.5 |
| F | 684 | ZZ | 4 | 9 | 10.3 |
| F | 685 | ZZ | 5 | 11 | 12.5 |
| F | 605 | ZZ | 5 | 14 | 16 |
| F | 606 | ZZ | 6 | 17 | 19 |
| F | 626 | ZZ | 6 | 19 | 22 |
| F | 607 | ZZ | 7 | 19 | 22 |
| F | 688 | ZZ | 8 | 16 | 18 |
| F | 608 | ZZ | 8 | 22 | 25 |
| ID | OD | Width | chamfer | LOADING(KN) | BALL | WEIGHT | |||
| Dynamic | Static | No. | Size | KG | |||||
| Cr | Cor | mm | |||||||
| 6000 | 10 | 26 | 8 | 0.3 | 4.55 | 1.95 | 7 | 4.763 | 0.019 |
| 6001 | 12 | 28 | 8 | 0.3 | 5.1 | 2.39 | 8 | 4.763 | 0.021 |
| 6002 | 15 | 32 | 9 | 0.3 | 5.6 | 2.84 | 9 | 4.763 | 0.035 |
| 6003 | 17 | 35 | 10 | 0.3 | 6.8 | 3.35 | 10 | 4.763 | 0.04 |
| 6004 | 20 | 42 | 12 | 0.6 | 9.4 | 5.05 | 9 | 6.35 | 0.068 |
| 6005 | 25 | 47 | 12 | 0.6 | 10.1 | 5.85 | 10 | 6.35 | 0.079 |
| 6006 | 30 | 55 | 13 | 1 | 13.2 | 8.3 | 11 | 7.144 | 0.113 |
| 6007 | 35 | 62 | 14 | 1 | 16 | 10.3 | 11 | 7.938 | 0.149 |
| 6008 | 40 | 68 | 15 | 1 | 16.8 | 11.5 | 12 | 7.938 | 0.185 |
| 6009 | 45 | 75 | 16 | 1 | 21 | 15.1 | 12 | 8.731 | 0.231 |
| 6010 | 50 | 80 | 16 | 1.1 | 21.8 | 16.6 | 13 | 8.731 | 0.256 |
| 6200 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 8 | 4.763 | 0.032 |
| 6201 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 7 | 5.953 | 0.037 |
| 6202 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 8 | 5.953 | 0.045 |
| 6203 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 8 | 6.747 | 0.066 |
| 6204 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 8 | 7.938 | 0.106 |
| 6205 | 25 | 52 | 15 | 1 | 14 | 7.85 | 9 | 7.938 | 0.128 |
| 6206 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 9 | 9.525 | 0.199 |
| 6207 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9 | 11.112 | 0.288 |
| 6208 | 40 | 80 | 18 | 1.1 | 29.1 | 17.8 | 9 | 12 | 0.366 |
| 6209 | 45 | 85 | 19 | 1.1 | 32.5 | 20.4 | 10 | 12 | 0.398 |
| 6210 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 10 | 12.7 | 0.454 |
| 6300 | 10 | 35 | 11 | 0.6 | 8.2 | 3.5 | 6 | 7.144 | 0.053 |
| 6301 | 12 | 37 | 12 | 1 | 9.7 | 4.2 | 6 | 7.938 | 0.06 |
| 6302 | 15 | 42 | 13 | 1 | 11.4 | 5.45 | 7 | 7.938 | 0.082 |
| 6303 | 17 | 47 | 14 | 1 | 13.5 | 6.55 | 7 | 8.731 | 0.115 |
| 6304 | 20 | 52 | 15 | 1.1 | 15.9 | 7.9 | 7 | 9.525 | 0.144 |
| 6305 | 25 | 62 | 17 | 1.1 | 21.2 | 10.9 | 7 | 11.5 | 0.232 |
| 6306 | 30 | 72 | 19 | 1.1 | 26.7 | 15 | 8 | 12 | 0.36 |
| 6307 | 35 | 80 | 21 | 1.5 | 33.5 | 19.1 | 8 | 13.494 | 0.457 |
| 6308 | 40 | 90 | 23 | 1.5 | 40.5 | 24 | 8 | 15.081 | 0.63 |
| 6309 | 45 | 100 | 25 | 1.5 | 53 | 32 | 8 | 17.462 | 0.814 |
| 6310 | 50 | 110 | 27 | 2 | 62 | 38.5 | 8 | 19.05 | 1.07 |
