608 Full ZrO2 Ceramic Skate Bearing
We are special in making Silicone Nitride Balls (Si3N4 Balls,Zicronia Balls (ZrO2 Balls),Sic Ceramic Balls ,
Aluminum Oxside Valve (AI203) ceramic balls.
Compared with steel, ceramic materials are noted for their better or particular characters, such as wear-resistance, corrosion resistance, high temperature resistance, electrical insulation (except SiC), nonmagnetic,
high strength, high rigidity, and low specific gravity. These properties qualify them for replacing steel to
make bearings serve in conditions of higher speed, harsh environment and less lube, and decrease wear, noise,
vibration and maintenance time of bearings, and eventually increase performance, reliability and life of bearings.
FULL CERAMIC BEARINGS
Full Ceramic Bearings are made entirely of ceramic material and are superior to common steel bearings in many
ways. Ceramic is the perfect material for any application seeking to achieve higher RPM’s, reduce overall weight or
for extremely harsh environments where high temperatures and corrosive substances are present. Applications
such as cryopumps, medical devices, semiconductors, machine tools, turbine flow meters, food processing equipment,
robotics and optics. Ceramic materials commonly used for bearings are Silicon Nitride (Si3N4), Zirconia Oxide (ZrO2),
or Silicon Carbide (SiC.)
Hybrid Ceramic Bearing:
Ceramic bearings offer a significant performance improvement from those made from traditional steel. Our ceramic bearings are manufactured from silicon nitride (Si3N4), an exceptionally hard non-metallic material rated for speeds to 2 million dN, offering a wide selection of benefits.
Hybrid Bearings have steel rings and ceramic balls. Si3N4 Ball is the most popular for the balls as it has only 40 percent of the density of bearing steel but is much harder giving greater wear resistance. Zirconia is heavier with 75 percent of the density of steel so is less suitable for hybrid bearing.
Bearing No | Bore d(mm) | O.d D(mm) | Width B(mm) | Load Rating | Weight (kg) | |
Dynamic | Static | |||||
606 | 6 | 17 | 6 | 1.13 | 0.56 | 0.006 |
607 | 7 | 19 | 6 | 2.01 | 1.05 | 0.008 |
608 | 8 | 22 | 7 | 2.53 | 1.36 | 0.015 |
609 | 9 | 24 | 7 | 2.53 | 1.36 | 0.016 |
if you need, please contact me freely.
Connie
Email: connie at
Whatsapp:+8615073676619
Wechat:empty919
