U Groove Track Roller Bearing for Enboridery Machine

U Groove Track Roller Bearing for Enboridery Machine thumbnail-1
U Groove Track Roller Bearing for Enboridery Machine photo-1
US$ 0.5 - 2 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
NTL
Bore Size:
2, 50
Outside Diameter:
13, 110
Contact Supplier Request Quote Chat Now
Changsha Terry Machinery Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name NTL
Bore Size 2, 50
Outside Diameter 13, 110
Model Number LFR 50/4
Precision Rating high precision
Seals Type NPP KDD
Number of Row Other
Place of Origin Jiangsu, China

V/U grooveTrack roller bearing LFR type



Guide Way Ball Bearing

1. Series LFR rollers are the most widely-use and economy product among the linear motion track rollers, and they can suit to the cylindrical track.
2. There are two contact points between the roller and track, so the contact function is favorable.
3. Rollers feature double row angular contact ball bearing in its internal structure design and a thick-walled outer ring, so rollers can accommodate higher loads.





bearing
 code		 weight
(g)		 dimension(mm) load rating
dw d D C B A rs Cw
(KN)		 Cow
(KN)		 Fr perm
(KN)
LFR 50/4 NPP 3.5 5 4 13 6 7 8.04 0.2 1.05 0.85 1.15
LFR 50/5-4 KDD 7.5 4 5 16 7 8 9 0.2 1.2 0.86 1.3
LFR 50/5-4 NPP 7.5 4 5 16 7 8 9 0.2 1.2 0.86 1.3
LFR 50/5 KDD 8 6 5 17 7 8 10.5 0.2 1.27 0.82 1.3
LFR 50/5 NPP 8 6 5 17 7 8 10.5 0.2 1.27 0.82 1.3
LFR 50/8 KDD 24 6 8 24 11 11 14 0.3 3.67 2.28 1.3
LFR 50/8 NPP 24 6 8 24 11 11 14 0.3 3.67 2.28 1.3
LFR 50/8-8 KDD 24 8 8 24 11 11 14.75 0.3 3.67 2.28 1.3
LFR 50/8-8 NPP 24 8 8 24 11 11 14.75 0.3 3.67 2.28 1.3
LFR 30/8 KDD 31 10 8 26.8 11 13 16.7 0.3 3.67 2.28 1.3
LFR 30/8 NPP 31 10 8 26.8 11 13 16.7 0.3 3.67 2.28 1.3
LFR 5201 KDD 68 10 12 35 15.9 15.9 20.65 0.3 8.5 5.1 5.1
LFR 5201 NPP 68 10 12 35 15.9 15.9 20.65 0.3 8.5 5.1 5.1
LFR 5301 KDD 130 10 12 42 19 19 24 0.6 13 7.7 7.5
LFR 5301 NPP 130 10 12 42 19 19 24 0.6 13 7.7 7.5

U groove track roller bearing for enboridery machine

Welcome your inquiry of the track roller bearing.

Sales manager:dana

Skype:danalove329



U groove track roller bearing for enboridery machine
