SF1 series crimping Bronze bushing with PTFE 20MM
- 1000000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
Product Details
Brand Name: | NTL | Model Number: | 20mm | Place of Origin: | Zhejiang, China |
Product Description
PTFE Coated DU & DUB Bush Bearing for Rotary Gear Pumps
PTFE+Bronze bush bearing
ID | OD | SHAFT | HOLEH7 | THICKNESS | f1 | f2 | L | ||||||||||
Min. | Max. | 6 | 8 | 10 | 12 | 15 | 20 | 25 | 30 | 40 | 50 | ||||||
6 | 8 | 6 | 8 | 0.980 | 1.005 | 0.5 | 0.3 | 0606 | 0608 | 0610 | |||||||
8 | 10 | 8 | 10 | 0806 | 0808 | 0810 | 0812 | 0815 | |||||||||
10 | 12 | 10 | 12 | 1006 | 1008 | 1010 | 1012 | 1015 | 1020 | ||||||||
12 | 14 | 12 | 14 | 1206 | 1208 | 1210 | 1212 | 1215 | 1220 | 1225 | |||||||
13 | 15 | 13 | 15 | 1310 | 1320 | ||||||||||||
14 | 16 | 14 | 16 | 1410 | 1412 | 1415 | 1420 | 1425 | |||||||||
15 | 17 | 15 | 17 | 1510 | 1512 | 1515 | 1520 | 1525 | |||||||||
16 | 18 | 16 | 18 | 1610 | 1612 | 1615 | 1620 | 1625 | |||||||||
17 | 19 | 17 | 19 | 1710 | 1712 | 1720 | |||||||||||
18 | 20 | 18 | 20 | 1810 | 1812 | 1815 | 1820 | 1825 | |||||||||
20 | 23 | 20 | 23 | 1.475 | 1.505 | 0.8 | 0.4 | 2010 | 2012 | 2015 | 2020 | 2025 | 2030 | ||||
22 | 25 | 22 | 25 | 2210 | 2212 | 2215 | 2220 | 2225 | 2230 | ||||||||
24 | 27 | 24 | 27 | 2415 | 2420 | 2425 | 2430 | ||||||||||
25 | 28 | 25 | 28 | 2510 | 2512 | 2515 | 2520 | 2525 | 2530 | 2540 | 2550 | ||||||
28 | 32 | 28 | 32 | 1.970 | 2.005 | 1.0 | 0.5 | 2815 | 2820 | 2825 | 2830 | 2840 | |||||
30 | 34 | 30 | 34 | 3012 | 3015 | 3020 | 3025 | 3030 | 3040 | ||||||||
32 | 36 | 32 | 36 | 3220 | 3230 | 3240 | |||||||||||
35 | 39 | 35 | 39 | 3512 | 3515 | 3520 | 3525 | 3530 | 3540 | 3550 | |||||||
38 | 42 | 38 | 42 | 3815 | 3830 | 3840 | |||||||||||
40 | 44 | 40 | 44 | 4012 | 4020 | 4025 | 4030 | 4040 | 4050 | ||||||||
Company Profile
Changsha Terry Machinery Co., Ltd. is located in Changsha. Our company enjoys convenient transportation and advanced economy.
We have been exporting bearings for 8 years. Our main products are Needle Roller bearings, Cylindrical Roller Bearings, Rod end Bearings, Spherical plain bearings, Track roller Bearings for Guideway, Roller Bearings, Combine Bearings for forklifts, Water Pump Bearings, SNR Auto Bearings and all kinds of Spherical Bearings. We have exported our products to Korea, Iran, Turkey, Bulgaria, Romania, Russia, Italy, Norway, the USA, Canada, etc. We offer OEM service. Our products are applied in many fields.
Our Advantages
Products
Big volume in Stock, No MOQ required
We comply with all the international standards, such as ISO9001 and TS16949 standards.
Personnel
Our sales persons are well trained to accommodate your requests and speak English for your convenience.
Our technicians and engineers have 23 years of Experience in the Bearing Industry.
Service & Quality control
We supply detailed drawings and offer whenever necessary.
We inspect every piece of bearing by ourselves before delivery.
