D900 CANSCAN OBD2 Live PCM Data Code Reader Scanner

D900 CANSCAN OBD2 Live PCM Data Code Reader Scanner

Features:

Display: backlight 128 x 64 pixel display
with contrast adjustment
easy-to-read screen and also saves up to 15
scans for later viewing.
Operating temperature: 0-50 C (-32 to 122F)
External power: 8.0 to 15.0 volts provided
by vehicle battery
Internal Power: 3 AAA battery (included)
This is an OBDII and EOBD scanner which supports the following protocols:
CAN
KWP 2000
ISO 9141-2
PWM
VPW
The D900 CanScan is brand new and is supplied with: scanner unit OBD II connector cable, disc with comprehensive user manual, OBD information and compatibility list and padded storage case with wrist strap.
Specifications:
Power: directly from the vehicle or by X3 AA batteries
Unit dimensions: 9 x 20 x 3cm / 3.3 x 8 x 1.2" (W x L x D)
Screen dimensions: 6 x4.5cm / 2.3 x 1.6" (W x L)
Cable length: 109cm /43"
Compatibility:
Supports ISO, VPW and PWM bus systems as well as can bus systems
U.S. Models - European - Japanese - Asian - German - Korean:
Suitable for almost all cars after 1996 .
GM '96 - Current Year (OBD-II)
Ford '96 - Current Year (OBD-II)
Chrysler '96 - Current Year (OBD-II)
Toyota '96 - Current Year (OBD-II)
Honda '96 - Current Year (OBD-II)
NISSAN '96 - Current Year (OBD-II)
All other - Asian and European '96 - Current Year (OBD-II)
Description:
1. An essential piece of kit for all car and van owners save time and money with this hand held
OBDII ScanTools which enables you to troubleshoot any problems in your vehicle by
reading the Diagnostic Trouble Codes (DTC) that appear when the "check engine" light is
showing.
2. DTCs are codes that are stored by the car's in-board computer system in response to a vehicle
issue.

3. Codes relate to a particular problem and are made up of a 5 digit alphanumeric
sequence and are used as a guide to help locate the fault in order for you to fix the vehicle.
4. This scanner has CAN Protocol Support which gives wider vehicle coverage.

5. It resets the check engine lights, reads and clears all generic, and some manufacturer specific, DTC,
displays the I/M readiness status, views OBD II freeze frame data, displays pending codes,
retrieves vehicle information (VIN), and determines the status of the malfunction indicator
(MIL) lamp.
6. Help prevent costly future engine trouble and identify problems when buying or selling a
used vehicle with the MULTOBD scan tool.
Functions:
1. Displays the DTC definitions on screen unlike previous models
2. Wider coverage: works with CAN-equipped vehicles
3. Reads and clears all generic, and some manufacturer, specific DTCs
4. Resets check engine lights
5. Views OBD II Live data
6. Views OBD II freeze frame data
7. Displays I/M readiness status
8. Retrieves the Vehicle Identification Number (VIN)
9. Determines the malfunction indicator lamp (MIL) status
10.Hot keys for quick read and release
11.Hand held and easy to use with one plug-in only
12.Highly reliable and accurate
13.Safely communicates with the onboard computer
14.No batteries needed for operation powered via detachable OBD2 cable
15.Battery compartment for off-vehicle reviewing or for when upgrading from PC
Package contains:
1. Scanner with detachable OBD2 Extension Cable
2. Nylon carry pouch for transportation of the tool and it's accessories
3. CD-ROM that includes User Manual
