Mini Homeplug AV Ethernet Adapter 500M

Specifications

Mini Homeplug AV Ethernet Adapter 500M

Mini Homeplug AV Ethernet Adapter 7HP150

The Mini Homeplug AV 500Mbps 7HP150 is an Ethernet wallmount adapter which provides communication over any electrical wiring at the speed of up to 500Mbps. It provides a secure, stable Internet connection in places where wireless signals don’t reach, by turning any wall outlet into an Internet access point. No any installation,just connect the 7HP150 to PC by Ethernet cable,plug it into the power outlet,then you can connect your network-enabled devices throughout your home.It is so simple. 7HP150 is designed to support full multimedia home networking,supports Internet Television (IP-TV in HD quality), video-on-demand, VoIP Telephony and fast internet access IP TV and triple-play applications.

Features:

Connect a computer, HDTV, VOIP or gaming console. Just plug it in and you’re ready to go. Plug ‘n’ Play: no new wires, no software installation, no configuration required 500Mbps transfer speed & QoS, perfect for HD IPTV streaming One button Reset/Security Press to secure your network Instant indication of PLC network bandwidth through LED Advanced encryption technology to ensure data security on your PLC network Energy Saving technology, savings up to 60%

Applications:

Audio & Video transmission across the home for multiroom services Multiple High Definition (HD) and Standard Definition (SD) video programs PC files and applications sharing Voice over IP calls Printers, NAS and peripherals sharing Remote diagnostic and management of inhome PLC network High Speed Internet access sharing Network connection of online gaming console Network camera for distant home video surveillance

Casing Color: White Physical Dimensions: L:70 x W:56 x D:30 mm Unit weight: 110 grams LED Indicators: Power, Ethernet, Data External Connectors: 1 x Power Plug 1 x Ethernet LAN Port 1 x Button to press for an easy secure pairing between plugs and for a reset to return to initial configuratio

Accessories: 2 x Ethernet Cable 1meter 1 x QIG manual 1 X CD

Technical Speci cations Standards: Powerline: HomePlug AV Ethernet: IEEE 802.3 10/100 Auto MDI/MDIX Energy Saving: EuP Compliance Protocol: TCP/IP, IGMP, QoS CSMA/CA Data Transfer rate: Up to 500Mbps over powerline Transmission Range: Up to 200m over powerline Frequency band: 2Mhz to 30Mhz Security & Protection: 128-bit AES encryption (enabled with Simple Connect button) Modulation Technology: OFDM 1024/256/64/16/8 QAM, QPSK, BPSK and ROBO Modulation Scheme Power Consumption: Normal: less than3 Watt Power save: less than 1 Watt Average Operating System: Windows 98SE/ME/2000/2003/XP/Vista, Windows7, Linux, Mac OS Power Requirement: AC 100 ~240V, 50~60Hz Temperature: Operating: 0° to 40° Celsius Non-Operating : -25° to 70° C Humidity: Operating: 10%~90%, Non-condensing Non-Operating : 5%~90%, Non-condensing
