Specifications
VGA to HDMI Upscaler 1080PVGA to HDMI Upscaler 1080P
1.1Features
1.Scales general PC resolutions to HDMI 1080p output.
2.Provides advanced signal processing with great precision. Colors,resolutions,and details.
3.High quality scaling technology for progressive input resolutions.
VGA input Supports up to 1920x1080@60Hz.
2.0Specifications
Input ports:1xVGA,1x3.5mm PhoneJack.
Output port:1xHDMI
Dimensions(mm):66(D)x55(W)x20(H)
Wight (g): 40
Input Resolution:
1600x1200@60Hz,1920x1080@60Hz,
Output Resolution: 1080p/60Hz,720p/60Hz.
3.0Packing List:
Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping
1.VGA2 HDMI Converter------------------1pcs
2. USB Cable----------------------------------1pcs
3.User Manual------------------------------1PCS
4.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal input(s), output(s) and power requirements.
Back Panel: Top Panel: Front Panel:
AUDIO IN------------------Audio Input
VGA IN----------------------VGA Input
USB Power------------------USB Power Input
720P/1080P------------------720P or 1080 output switch
HDMI -----------------------HDMI Output
ZOOM------------------------Scaler
AUTO-------------------------Auto adjust
