Recognized by National Sewing Machine Quality Inspection & Test Centre, servo motor can save 71.22% electricity compared with clutch motor.
1. Wide voltage range design: can work between 85-250V, suitable for the regions with unsteady voltage;
2. Good anti-jamming design: can resist multiple electromagnetic interference from different devices;
3. Bigger torque: can be used on most industrial sewing machines, including lockstitch, overlock, coverstitch, as well as common heavy duty machine and shoe machine. Sewing steady, no stitch skipping;
4. PID control design: better handing quality, user can operate it easily;
5. Lower friction, lower noise & vibration, lower temperature rise, bring you a better work environment;
6. Agiler, more powerful, start time of 0 to 6000RPM is 0.2s;
7. Perfect dot sewing function: dot sewing means sew one stitch when press the pedal one time, it makes much easier to sew winding and complicate stitch, thereby reduce the reject sharply. Meanwhile, the stroke of the pedal is shorten and user can operate the pedal much lighter, so work intensity is reduced;
8. No power consume under holding state (compared with clutch motor), motor stops running when user stops sewing;
9. Needle stops quick, precise and steady.
Motor Name | Energy-saving servo motor for sewing machine |
| Motor Type | Bressless Permanent Magnet Motor |
| Voltage | Ac220, 110V |
| Output Power | 370W,550W,750W |
| Max. Speed | 6000rpm |
| Max. Torque | 370W: 2N/M; 550W: 3N/M; 750W: 4N/M |
| Needle Up/Down | Optional function (Synchro required) |
| Accelerate Time | 0.3s |
| Package | 10.8kg |
| Carton Size | 560x360x250(2pcs) |
Test Equipments
Our booth in Canton Fair
| Contacts : | Carl |
| Tel : | 0086-574-27896275 |
| Skype: | carl13208093502 |
| Whatsapp : | 13208093502 |
| QQ: | 2853257836 |
1) How can I place order?
A: You can contact us by email about your order details, or place order on line.
2) How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank) and Paypal, Western Union are the most usual ways we are using.
3) What’s the order procedure?
A: First we discuss order details, production details by email or TM. Then we issue you an PI for your confirmation. You will be requested to do pr -epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
4)How do you take care when your clients received defective products?
A: replacement. If there are some defective items, we usually credit to our customer or replace in next shipment.
5)How do you check all the goods in the production line?
A: We have spot inspection and finished product inspection. We check the goods when they go into next step production procedure.
A: Your inquiry related to our products or prices will be replied in 24 hours.
B: Protection of your sales area, ideas of design and all your private information.
C: Best quality and competitive price.
