55 Inch Did Lcd Display Seamless Lcd Video Wall (HQ550-V)

55 Inch Did Lcd Display Seamless Lcd Video Wall (HQ550-V) thumbnail-1
55 Inch Did Lcd Display Seamless Lcd Video Wall (HQ550-V) photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CHIMEE
Model Number:
HQ550-V
Contact Supplier Request Quote Chat Now
Shenzhen Chimee Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CHIMEE
Model Number HQ550-V
Type TFT
Application Other, indoor, mall , beauty shop,retail shop, hospital , school etc.
Panel Size 55 Inch
Max Resolution 1920 x 1080
Viewing Angle 178/178
Pixel Pitch 626mm x 878.90mm
Color 16.7M
Contrast Ratio 3000:1
Brightness 800dc/m2
Response Time 5ms
Input Voltage AC110V-240V, 50/60HZ

Specifications

55" lcd video wall
+indoor use
+full HD 1080p
+wide screen
+CE GOT

55 inch did lcd display seamless lcd video wall (HQ550-V) (Full HD 1920x 1080, optimal A+LCD panel)

Product NO.:   HQ550-V)



55 inch did lcd display seamless lcd video wall (HQ550-V)



55 inch did lcd display seamless lcd video wall (HQ550-V)













55'' DID Samsung Full highly defination LCD video wall







Features:



Narrow bezel design ---Industrial grade LCD panel ,high quality ,Practical ,good vision effect.



Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV



One Screen,Four Image,Image Roaming,M*N*4 dispaly



HD video wall unit--- High brightness,high contrast,High gamut .



Flexible structure design ---easy installation ,extensible,arbitrary combination



Stable performance,suitable working for a long time







Specifications
Model No. hq550-v
Panel Size 55" LG DID LCD Screen(with narrow bezel 5.3mm,with LED Backlight)
Display area 1210(W)*680.8(H)(mm)
Aspect Ratio 16:9
Max Resolution Support 1920x1080
Color 8Bit,16.7M
Brightness (nits) 700cd/m2
Contrast 4000:1
Visual Angle (H/V) 178°
Response Time <=6ms
Life(hrs) >60,000(hrs)
Input and output
DVI 1
HDMI 1
VGA 1
YPbPr 1(BNCx3)
S-video 1(BNCx2)
Composite Video Input/(AV) 3(BNCx3)
Composite Video Output 2(BNCx2)
Control signal input and loop out RS232(RJ45-8)
Split Screen Support Picture in Picture(PIP/POP)
Power
Power Supply AC100V~240V
Maximum Power Consumption 250W
Standby Power Consumption <=3W
Temperature
Working Temperature 0°C~50°C
Working Humidity 20%-80%
Dimension 1215.3mm × 686.1mmx116.2mm
Video Wall Controller(Built-in each Screen)
Model No. HQ550-V
Input CVBS 1*BNC port, support PAL / NTSC all formats
VGA 1*D15 port, support SVGA / XGA / WUXGA
DVI 1*DVI-I port,support SVGA / XGA / WUXGA
HDMI 5*BNC ports, support SVGA / XGA / WUXGA
Output LVDS Support signal or double LVDS output, and WUXGA (1920*1080) display
CVBS support PAL/NTSC all formats
DVI 1*DVI-I port,support SVGA / XGA / WUXGA
Operate mode Panel key operation(need customization)
Standard RS232 port( provide free control software)
ADD Code
Engineering software XK _LCD_CONTROL_Manager, RS232 interface control (1 input, 2 looping out)
Working temperature  0~70 °C
working humidity 5~95 %RH
AC voltage power supply 100-240V/50, 60Hz
power consumption Max 300W,according to different Screen models
Dimension 307×283×55(mm)
Weight About 3.5KG



We provide servise:



1. Customized requirment is available , OEM&ODM are welcome.



2. Reasonable and satisfactory solutions Provided to you by our professional engineers and staffs .



3. Warranty: one year overall unit ( Non-artificial damage )



Trade terms:



1.Price: Price coveres cost of controller &software,based on EXW SHENZHEN



2.Lead time:within 5-15working days after payment.



3.Payment terms:T/T,Western union,L/C.
