High Quality! Transport Foam Swabs

Specifications

1. Compressed, 100 PPI open-cell structure
2. Thermally bonded
3. Low particle
4. No silicon oil, amid, DOP
5. MOQ: 100 bags

Description:

Purestat^® Clean Foam swab employ the reticulated 100ppi foam to provide soft, absorbent cleaning performance. A variety of head shapes and sizes enabling precision cleaning of Optical, Disk Drive and Medical Device components. Manufacturing, cleaning and packaging is performed on an integrated line to ensure maximum cleanliness and lot to lot uniformity.



Application: HDD, Optics, Semiconductor and Biomedical Device industry



Features:

Compressed,100ppi open-cell structure with good water absorption.

Thermal bonding head, no chemical bond contaminations.

Available for cleaning small slotted and grooved areas.

Low particle generation and less contaminated ions.

No silicone oil, amide, DOP, etc.

Low non-volatile residue.



Parameter:

Nonvolatile residue test  IPA extractant DI extractant	mg/swab ≤0.40 ≤0.15	Ion Chloride Sulphate Total anion	μg/tip ≤0.9 ≤0.4 ≤1.3
LPC test(≥0.5μm) Particle counts/swab tip	< 25,000	No Silicone oil , DOP and Amide



P/N	Head Width (mm)	Head Thickness (mm)	Head Length  (mm)	Handle Width (mm)	Handle Thickness (mm)	Handle Length  (mm)	Total Swab Length (mm)	Packaging
PUF-2582	4.00	4.00	15.00	2.50	2.30	50.00	65.00	100pcs/pack; 5packs/bag.
