Specifications
offering repeatable checks on both right and left feet at the same timeaccuracy:5%
customer decide the specification
The product is made according to standard ISOICD8782-I,it can tes the resistance ofhand and feet's to grounding,also with LED display and alarm system, it is the indispensabl test in strument in controlling static electricity adopt battery with 9V,safely and with low voltage,auto-alarm as lack of voltage, the height can be adjusted freely
Using method
1. move the switch to "foot wear"in the left,puffing on ESD shoes,then stand on the test board, press the key "press to test",the indicator on the left is the resistance for the left shoe,and the right is the resistance for the right one
2.move the switch to "wrist stap",wearing wrist strap,and put the plug or alligator clip to jack(alligator clip pole),
press the key "press to test",the indicator on the right is the resistance for wrist strap.
| footwear | wrist strap | alarm | |
| HI | R>100M Ω | R>10M Ω | YES |
| PASS |
R>=750K Ω R<=100M Ω |
R>=750K Ω R<=100M Ω |
NO |
| LOW | R<750K Ω | R<750K Ω | YES |
| LOWBATT | Please change battery when<=7V | ||
Properties:
offering repeatable checks on both right and left feet at the same time
LED indicate one of the following High,pass,or low
standard test range :750K Ω - 100M Ω
high and low resistance' scan be altered for your relevant country
specificatton(customer decided)
accuracy:5%
weight:4.6kg
dimension of tester:190*138*34mm
height of station(adjust):0.6~1.07M(24''~42")
power requirement :9V alkaline battery
