Specifications
Our three spindle CNC router features a 1300*2500mm working area, square guide and rack gear. It features an advanced DSP systemCHINA JINAN the XJ1325 Three Spindle CNC Router With CE
Description
Our three spindle CNC router features a 1300*2500mm working area, square guide and rack gear. It features an advanced DSP system, vacuum table and dust collector. It offers a wholly cast and has CE certificate.
Application
The CNC woodworking machine can be used in the furniture processing industry, sign plate, acrylic cutting, plastic plate and even metal engraving like iron, aluminum, etc.
Technical Specifications of the XJ1325 Three Spindle CNC Router
| Model | XJ-1325 |
| Working area | 1,300×2,500×200mm |
| Spindle motor | 3KW Inverter-driven spindle motor cooled by water (or air for option) |
| Working mode | Stepper motor |
| Control system | DSP(128MB) or PCIMC control system |
| Drive mechanism | Gear-wheel on x, y axis |
| Table surface | T-slot extrusions |
| Frame | Wholly steel structure |
| Motion positioning accuracy | ± 0.03/300mm |
| Repositioning accuracy | ± 0.05mm |
| Max motion speed | 12,000mm/min |
| Max engraving speed | 8,000mm/min |
| Rotating speed of spindle | 2,4000rpm |
| Engraving tools | 2,4000rpm |
| Dictate format | G code, *.u00, *.mmg , *.plt |
| Operating voltage | 3phase 380v |
| Software | Type3 original with Dongle or Wentai , ArtCAM software |
| Packing size | 3350×1950×1990mm |
| Net weight | 1227kg |
| Gross weight | 1240kg |
Packing
The CNC router is packed in plywood case.
our company
XYZ-TECH is a China-based CNC router manufacturer and supplier. Our products include woodworking CNC router, laser engraving machine, plasma cutting machine, multifunctional CNC router, cutting plotter, laser cutting machine, CNC woodworking machine, etc
