High quality sale spindle motor cutting ceramic tile 3d+mini+router+cnc
We are manufacturer and specialized in cnc router ,laser engraving and cutting machine, plasma cutting machine
and cutter plotter, with 16 years production and sales experience
in this field and 8 year export and service experinece for overseas’ buyers.
Description:
>Two-motor drive system ensures quick, even, stable operation
>The vacuum cleaning system offers a clean working environment and better quality
>High performance Subdivision stepper motor operates smoothly at maximum speed.
>Highly accurate gears allow for engraving characters as small as 1.5mm
>The unique calculating system realizes speedy, accurate, curvy operation
>Large Water-cooled High-Frequency High-Power Motor features low noise, constant speed, and long operational life
>12 Month Warranty on parts and Labour
Technical specification:
| Model | XJ1212/XJ2030 | |
| Working Area | 1200×1200×200mm/ 2,000×3,000×200mm | |
| Spindle Motor | 3kw/4.5kw Inverter-driven spindle motor cooled by water (or air for option) | |
| Working Mode | Stepper motor | |
| Control System | DSP off-line control panel with USB interface(128MB) or PCIMC control system | |
| Drive Mechanism | Gear-wheel on x,y axis | |
| Table Surface | Vacuum table o& T-slot extrusions | |
| Frame | wholly steel structure | |
| Motion Positioning Accuracy | ±0.03/300mm | |
| Repositioning Accuracy | ±0.05mm | |
| Max Motion Speed | 50,000mm/min | |
| Max Engraving Speed | 30,000mm/min | |
| Rotating Speed of Spindle | 2,4000rpm | |
| Z-axis setting | Auto Z origin tool high sensor | |
| Dictate Formate | G code, *.u00, *.mmg, *.plt | |
| Operating Voltage | 3phase 380v | |
| Software | Type3 copy/original with Dongle or Wentai (ArtCUT), ArtCAM software | |
| Packing Size | 3350×1950×1990mm | |
| Lubrication System | Oil lubrication system | |
| Net weight/ Gross Weight | 1227kg/ 1240kg | |
| Noise Level | Racing | LAeep dB(A)72±1 |
| Engraving | LAeep dB(A)80±2 | |
| Engraving Peak | LAeep dB(C)95 | |
| Optional Parts | Dust Collecting System 2.2kw/3kw | |
| Vacuum Table with Air Pump (For XJ1224,1325) | ||
| Mist Sprayer and flume | ||
| Rotary device with Dia100mm/200mm | ||
| DSP System w/Portable Control Pad (128MB) | ||
Accessories of wood cnc router:
12pcs of Cutters, 2pcs ofCollets,Control Card. Spanner x 3, Brush, Double sided tape, Power cord, USB data cable.
Feature
1.T-slot Vacuum table with 6 vacuum zones, which can adsorb different size materials. You can also fix
the work piece by clamp.
2. Lathe bed welded with thick channel steels and square tubes; Processed by high temperature tempering treatment and vibrating stress relief (VSR) to reduce residual stress; Ensure excellent stability, not easy to be deformed
3. Adopt Taiwan HIWIN high precision square rail; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost; Z axis adopts Germany-made ball screw,with high precision and long life time.
4. Well compatibility: CAD/CAM designing software e.g. Type 3/Artcam/Wentai etc.
5. Has the function of re-carving after break point and power failure.
6. DSP system with USB interface, convenient operation. Off-line working, no need put a computer there.
7. Perfect lubricating system makes maintenance much easier.
8. Has duct-collect function. It will clean up the carving residuum and make the operations tidier and more convenient.
9.Advanced design of the machine make sure strong cutting and guarantee the engraving accuracy.
Sample picture:
Company introduction:
We started to produce Mechanical and Laser Engraving Machine in 1994. Nearly 20 years rich experience in producing saling
and service ensures you high quality machine and perfect service.
Our Export Percentage up to 81%~90%.
OEM Service Offered Design Service Offered Buyer Label Offered .
Guarantee & Aftersales Service of laser cutter machine price XJ 1212
1.Guarantee for one year
2.24-hour technical support by email or calling
3.User-friendly English manual for machine using and maintaining
4.Free technician training for large customers.
