1325 cnc router with mach3 control system with rotary system 4x8 ft cnc router machine
From 2007,we have expanded our bussiness to worldwide.In the past 12 years,so many clients all over the world cooperated with us and built a good business realtions.We have much experiece on our after-sale problems.
The machine picture:
Parameter:
Model | XJ1325 |
X Y Z working area | 1300x2500x300mm |
Guide rail | square guide rail |
Max moving speed | 28000mm/min |
Max engraving speed | 20000mm/min |
Max material height | 200mm |
Resolution ratio | 0.005mm |
Repeat position accuracy | 0.05mm |
Command code | G code, U00, Mmg, Plt. Eng |
System environment | Windows98/2000/XP |
Working voltage | 380/220/110v |
Spindle power | 3KW water cooling spindle |
Spindle speed | 0-24000rpm/min |
Working way | 450B Stepper motor and driver |
Control system | mach3 control system |
Rotary system | 200mm diameter,2500mm length |
Package size | 2300x3270x1910mm |
Weight | 1200/1400kg |
Optional parts | cylinder rotary attachment/dust collector /vacuum adsorption |
Standard features:
1) Lather bed is cast by iron, strong and never out of shape. The unit adopts casting framework,
X,Y axis adopts gear wheel and rack transmission, Z axis adopt precise ball-screw transmission,
2) imprted high precision square linear, ensuring the working speed and precision.
3) It adopts high speed stepper motor and drivers,two motors for Y axis, max working speed is
25/min, with water cooling spindle highly upgrade the processing speed.
4) The machines Adopt advanced DSP digit-control system.
5) Well capability: CAD/CAD designing sofeware (type 3/ ArtCAM/ Castmate/ Wentai etc)
6) Vacuum table with 6 vacuum zones, which can absorb different size materials.
7) The vacuum cleaning system offers a clean working environment.
Applicable areas:
1.Furniture processing industry
2.Decoration
3.Wooden art crafts
4.Wood furniture engraving
Samples:
If you do not know our machine can process your material or not, do not worry, tell me,
I will help you!
Our machine:
| cnc router | laser machine |
XJ3030,XJ3636,XJ6060,XJ6090,XJ1212,XJ1218, XJ1224,XJ1325 | XJ3050,XJ6040,XJ6090,XJ1390,XJ1380,XJ1325 |
If you want to cut metal, our plasma cutting machine is the proffessional for processing the metal.
XJ1330,XJ1325,XJ1318.
1 We will provide the user a CD to study the machine installation and commissioning.
2 Our technicists can give user online guide.
3 The user can by call or email us any problems at any time.
4 One year warranty for machine maintenance, for equipment maintenance over the warranty
period is clearly marked.
1) What payment you accept?
1,T/T inadvance 2.western union 3 . Trade Assurance
2) I did not imported before , how should i do ?
You only need pay to us , we will arrange all the things to you and teach you how to do .we will
prepare all the documents to you , you don't need worry , because we know what you need .
3) Do You Arrange the ship For us?
Yes ,for FOB or CIF price, we will arrange shipment for you.
4) How about the documents after shipment?
We‘ ll send all original documents to you by DHL, for example :the Packing List, Commercial
Invoice, B/L, and other certificates as required by clients.
