1. Applications of Ultrasonic plastic film welding machine :
It is used for welding and forming of large Toys, Stationery, Non-woven Fabrics, Photo Album, etc.
2. Features of ultrasonic plastic film welding machine
a. The large base with attractive appearance is stable and durable. Thick pillar is equipped on
this machine to avoid movement backward of the transducer system.
b. Precise screws are used to control movement of the Transducer System up and down. So it is stable and saves effort.
c. Overcurrent protective device is installed to reduce fault and ensure the machine work
normally.
d. High quality, efficiency and output power. Spare parts are made in Japan, West Germany,
Taiwan, etc.
e. Horizontal position of the transducer system is adjusted by four Fine Adjustment Screws. So
the horn can be adjusted precisely and conveniently. And then it can weld products evenly.
Product pass rate will be improved.
f. Warranty for the whole machine is one year.
Specifications |
JD-1020 |
output power |
1000W |
frequency |
20K Hz |
input voltage |
AC220V |
welding head stroke |
75mm |
vibration head cooling system |
air-cooled |
oscillating system |
Self-excited oscillation circuit |
output time |
0.01-9.99S |
pressure |
1-7bar |
power output range |
1-6 stall continuously adjustable |
welding area (mm) |
90 |
Dimension |
400 × 660 × 900 |
Net Weight |
110kg |
