Guangdong Ultrasonic Welding Machine Manufacturers

Guangdong Ultrasonic Welding Machine Manufacturers photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
jieda ultrasonic
Model Number:
JD-10A
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name jieda ultrasonic
Model Number JD-10A
Voltage 220V, 220V
Power 1000W, 1000w-4200w
Frequency 20KHZ, 15khz
Welding Area 80MM
Dimensions 400*660*900
Weight 110KG
Usage welding

Guangdong ultrasonic welding machine manufacturers







Ultrasonic used of welding machine:





Apparel, appliance, automotive, electronics, filtration, home furnishings, medical, and packaging are just some of the industries that can utilize ultrasonic welding





Weldable thermoplastic resins can be categorized as amorphous or crystalline.

Weldable AMORPHOUS resins include:  polycarbonate, polyphenylene oxide, polystyrene, ABS, polyetherimide, acrylic, and polysulfone. Weldable CRYSTALLINE materials include:  thermoplastic polyester, nylon, acetal, polyethylene, polyphenylene sulfide, and polypropylene.

Yes, a limited number of dissimilar, amorphous thermoplastics can be welded together (e.g., ABS and polycarbonate). Melt temperature difference for dissimilar materials can't be greater than 50° F.





Advantage of Ultrasonic Plastic Welders:



Ultrasonic plastic welding is instant and efficient.  The process is simple and yields high productivity.  Ultrasonic plastic welding reduces labor cost and the need to use fasteners and yields cleaner looking assemblies





Parameters of ultrasonic plastic welders:



Specifications

JD-1520Z

JD-2020Z

JD-2215Z

JD-2615Z

output power (W)

1500

2000

2200

2600

frequency

20KHz

15KHz

input voltage

AC220V

welding head stroke

80mm

oscillating system

Self-excited oscillation circuit

output time

0.01-9.99S

current directions

output amplitude of the table instructions

pressure

pressure range of 1-7bar

power output range

1-4 stall continuously adjustable

vibration head cooling system

air-cooled

welding area   (mm)

150

190

 210

220

Dimension

600 × 680 × 1780

net

145kg

150kg

156kg

168kg





Guangdong ultrasonic welding machine manufacturers

  Welding material table:



 Guangdong ultrasonic welding machine manufacturers





 Guangdong ultrasonic welding machine manufacturers
