Specifications
DK 1325 cnc router machineimported linear track
advanced DSP system
all steel machine body
3 KW water cooled spindle motor
DK 1325 cnc route machine
Application:
DK 1325 cnc router machine can be used to process any woody products ,applicable to processing, advertising sign plate, acrylic cutting etc. Any metal or non-metal material can be processed ,for example ,iron, copper, aluminum, plastic plates and wood ,etc.
Distinguish Features:
1) Furnishing with high power inverter ---driven spindle motor cooled by water;
2) Optimization of mechanical and electrical design, ensure motion speed to be up to 25m/min.
3) Adopting high precision liner track can ensure more stable running at high speed with high accuracy.
4) Furnish with DSP controlling system, can also realize transmitting date by USB Flash Disk directly.
Technical data
Model |
DK1313 |
DK1318 |
DK1325 |
DK1630 |
DK2030 |
|
Working area |
1300×1300×150mm |
1300×1800×150mm |
1300×2500×150mm |
1550×3000×150mm |
2000×3000×150mm |
|
Spindle motor |
2.2kw inverter-driven spindle motor cooled by water |
3kw inverter-driven spindle motor cooled by water |
||||
Motion speed |
25000mm/min |
|||||
Rotating speed of spindle |
24000rpm |
|||||
Engraving tools |
3.175mm/6mm |
6mm/12.7mm |
||||
Dictate format |
G code |
|||||
resolution |
0.01mm |
|||||
Optional configuration:
servo system of Panasonic from Japan is optional ,whole machine can be running at 60m/min ,working speed can be up to 40m/mn when configuring servo system .
Dust collecting System (optional)
Vacuum System (optional)
Performance Features
1) Synchronization of processing curves and straight lines can be up to speed of 25m/min.
2) Standard allocation of 128M, realize transmitting data by USB Flash Disk directly, which can save 30 processing files simultaneously
USB interface, work without computer, not occupying computer resources.
3) Be compatible with CAD/CAM software: Type3/Artcam/Casmate/Proe, etc
4) Restoring from power off, continuation on break points, anticipate working time, user-friendly designing.
