SUDA MINI CNC ROUTER /CNC ENGAVER/ CNC CUTTER FOR SIGN MAKING-sd3025Y

Model

SD3025Y  New modle from SHANGHAI EXHIBITION July

Table size (cm)

30*25

X Y Z Guide

Rolling ball screw from Germany,X,Y,Z axis all configured with imported Linear rail,more processing accuracy .

XYZ movement (mm)

300 x 250 x 60

Spindle power

1500W

Spindle speed (min/max)

6000 - 24000 U/Min.

Machine dimension (cm)

56*54*59

Packing dimension (cm)

66*64*69

Weight (kg)

230KG

Power consumption without spindle

More than 1000w

Speed max.

0-70mm/s

Working speed max.

70mm/s

Stepper or servo motor?

Stepping motor

XYZ accuracy

 0,02mm

Reposition accuracy

 0,001mm

XY resolution

 0,001mm

Z resolution

 0,001mm

Table surface

IRON CASTTABLE

XY drive configuration

  roll screws

Z drive configuration

roll screws

Included Software

 Type3 V4.3 english

Software Compatible with

 Win98/Win2000/XP

Spindle coolin system

 water cooled

Spindle collet

ER11

Software transmission language

 G-Code, HPGL

Interface

Transimt the file from USB flask disk  directly

Voltage

220VAC/50-60Hz

Running environment

 0-35°C, humidity: 10-70%

Production time

10 working days when we received all the payment by T/T
