Specifications
10kw imported spindle motorpowerful driver motor
square linear rail
high helical rack rail
excellent electric connector
SUDA newest Atc Cnc Router With Range Drill on sale
woodworking cnc router Features:
1.Feeding Material by side on the new design, one-armed ganrtry of high strength, perfect match with automatic feeding system, over-wide material processing
2.Heavy body with super thick steel materials, professional engineering mechanical structure
&dynamic design, high temperature tempering treatment, enhance the rigidity of the machine,
reduce the deformation rate of equipment of heat, improve the stability and the processing
precision of machine
3.Configured with imported gang drill, can be arbitrary permutation and combination of vertical
drilling, sidetracking, single drill, and other multifunctional drill mode.
4.imported high power spindle from Italy, low sway in axial , strong cutting force, long lifetime,
low noise. with imported Geneva Type library of 8pcs tool, high efficiency
5.Electronic controlling cabinet adopted air cooling cycle , famous international electric parts
and industrial controlling system, stable performance , perfect function, prolong lifetime.
6.Imported professional vacuum table , adopt non-pipe adsorption base and imported German professional vacuum pumps, strong adsorption
capacity, high working efficiency
One time clamping can finish multiply processing.
7.Equipped with waste transfer device, more efficiency.
wooworking cnc router Application:
Applicable to process kinds of plate material, such as MDF, particleboard, PVC, fire-proof board, blockboard, engineering plastics and other materials, widely used in industry
of all kinds of furniture, computer tables and chairs, wooden doors, cabinets, musical
instruments, audio wood shell, sewing machine table etc.
woodworking cnc router Technical data:
Item |
HP3313 |
HP4313 |
|
Working size |
3500*1500*250mm |
4300*1300*250mm |
|
Table size |
3500*1500mm |
4300*1300mm |
|
Max. Travel speed |
X axis-60m/min, Y axis-40m/min Z axis -20m/min |
||
Transmitting |
X,Y- high accuracy helical gear ,Z-rolling ball screw |
||
Servo type |
Japan YASKAWA |
||
Spindle |
Italy 10KW ATC spindle motor |
||
Spindle rev. |
18000-24000rpm |
||
Vacuum table |
Mobile adsorption/6 set |
||
Pump type |
Becker from Germany (optional) |
||
Tool type |
Geneva type |
||
Tool magazine |
8pcs(10pcs,12pcs is optional) |
||
Controlling system |
SYNTEC(OSAI is optional) |
||
Voltage |
380V/3PH/50HZ |
||
Machine size |
4600*2500*2300MM |
5600*2500*2300MM |
|
Weight |
4500KG |
5500KG |
|
Note:
we could offer different working size cnc router advertising according to customers' requirements .best quality and best price cnc machine , professional technical
support ,you are welcome to inquiry .
