Help CenterSUDA Single Gantry Side Wood Door ATC Machine
Related Products
-
SUDA Single Gantry Side Multipurpose WORKING ATC MachineNegotiableMOQ: 1 Set -
SUDA Single Gantry Side Kitchen Top ATC MachineNegotiableMOQ: 1 Set
-
SUDA WOOD DOOR CNC ROUTER -MG1325CNegotiableMOQ: 1 Set
-
SUDA FUNITURE ATC CNC ROUTERNegotiableMOQ: 1 Set
-
WOODEN WOKEING FERNITURE CNC HOT CENegotiableMOQ: 1 Set
Specifications
1.SINGLE GANTRY SIDE ATC MACHINE2. COLOMBO SPINDLE MOTOR
3.THK LINEAR RAIL
4. GENEVA TYPE TOOL MAGAZINE
5.SYNTEC SYSTEM
Performance features
- a. Side feeding material of new design,more convenient.one-armed gantry of high strength,more efficiency.
- b. Integral welding frame of industrial ,tempering vector efficiency of processing,without deformation improve stability and precision of machine.
- c. Transmission part adopts high precision helical rack,THK linear rail from japan,supplement with japan Yaskawa servo system and Taiwan professional deceleration device,ensure machine running smoothly in high speed,high precision,low noise.
- d. Equipped with professional vacuum system,adopt adsorption base of integral steel structure,specialized material matrix surface with high strength and toughness,adopt professional”becker”vacuum pump from from German,strong adsorption capacity,high efficiency.
- e. Industrial controlling system professional and perfect function,stable performance,strong software compatibility.
- f. Thousands of classification precision hidden non-interference automatic tool feeding,one operation can finish whole database work, automatic lifting dust head,automatic oil lubrication system,more convenient,simple maintenance.
Application
Applicable to process kinds of plate material,such as MDF,shaving board,PVC,fire-proof board,blockboard,engineering plastics and other materials,widely used in solid wood doors, cabinets,bathroom cabinet,game cabinets,wave board,screen fields etc .
Technical data
item |
MP2513 |
MP3015 |
Working size |
2500*1300*210mm |
3000*1500*210mm |
Table size |
2440*1220mm |
2940*1430mm |
Max.travel speed |
X axis-60m/min,Y axis-40m/min,Z axis-20m/min |
|
transmitting |
X,Y-high accuracy helical gear,Z-rolling ball screw |
|
Servo type |
Japan YASKAWA |
|
spindle |
Italy 10kw ATC spindle motor |
|
Spindle rev. |
18000-24000rpm |
|
Vacuum table |
Matrix vacuum table |
|
vacuum type |
Moporo(Germany becker is optional) |
|
Tool type |
Geneva type |
|
Tool magazine |
8pcs(10pcs,12pcs is optional) |
|
Controlling system |
SYNTEC(OSAL is optional) |
|
Voltage |
AC380V/3PH/50HZ |
|
Machine size |
3200*2100*2000mm |
3700*2300*2000mm |
weight |
3500KG |
4200KG |
Note:Any changes of technical parameters without notice,price changed with different configuration and size.
