pcb carving cnc router machine1 CE CNC Router 6090
2 advanced CNC technology
3 segmentation design
pcb carving cnc router machine
Application:
Can be used to engrave and cut wood, metal like AL and Cu and alloys, marble, glass, plastic, plastic, rubber, organic glass, density fiber board, PVC/acryl board, Perspex, Composite panel, MDF, etcmake, PCB, 3d engraving, model making and other materials.
Machine body: |
whole cast iron |
Work dimensions: |
600 x 900 x 65mm |
Body dimensions: |
800 x1200 x 1200mm (with bracket) |
Z-axis working area: |
65mm |
Max. Feeding height: |
110mm or bigger |
Cut thickness of material: |
≤30mm |
Max. Speed: |
6000mm/min |
Working speed: |
0 - 4000mm/min |
Mechanical precision: |
0.01mm |
Max. Power consumption: |
1.6kW |
Power source: |
AC 220/50Hz |
Driver type: |
stepper motor |
Spindle: |
1.5kw variable speed, water-cooled motor |
Spindle speed: |
0 - 24000rpm |
Blade diameter: |
3.175mm, 6mm, 8mm, and 12.7mm |
| Software support: | ArtCAM, Ucancam V9 |
Command: |
HPGL, G code, u00, mmg, plt |
| Control system | DSP with USB connection |
Running circumstance temperature: |
0 - 45°C |
| Relative humidity: | 30% - 75% |
Warranty: 1 year
please add my skype rabbitlaserkim for more information about our machines.
