Garment/Textile/Fabric Cutting Machine

Garment/Textile/Fabric Cutting Machine thumbnail-1
Garment/Textile/Fabric Cutting Machine thumbnail-2
Garment/Textile/Fabric Cutting Machine thumbnail-3
Garment/Textile/Fabric Cutting Machine thumbnail-4
Garment/Textile/Fabric Cutting Machine thumbnail-5
Garment/Textile/Fabric Cutting Machine thumbnail-6
Garment/Textile/Fabric Cutting Machine photo-1
Garment/Textile/Fabric Cutting Machine photo-2
Garment/Textile/Fabric Cutting Machine photo-3
Garment/Textile/Fabric Cutting Machine photo-4
Garment/Textile/Fabric Cutting Machine photo-5
Garment/Textile/Fabric Cutting Machine photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
IECHO
Model Number:
BK2516
Contact Supplier Request Quote Chat Now
Hangzhou IECHO Science Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name IECHO
Model Number BK2516

1.System Components



BK cutting system includes electrical control box, cutting main body, pump, air compressor and other accessory parts.



According to customer's requirements, we will configure the following one tool or several tools: tangential knife, oscillating knife, driven rotary knife, V-cut, creasing wheel, punching knife and CNC router.



2.Technical Parameters



Cutting Effective Area

2.5m×1.6m;1.7m×1.3m;1.3m×1.1m

Max. External Dimension

3.32m×2.46m;2.52m×2.16m

Max. Cutting Speed

1.8m/s

Cutting Accuracy

0.1mm

Max. Cutting Thickness

50mm(According to customer's materials)

Data Formats

DXF, HPGL

Memory

8M

Working Voltage

AC power 380V±10%, 220V±10%,50HZ

Fuse Specification

10A

Cutting System Power

1.5KW

Drive Motor

Servo Motor

Pump Vacuum

-25KPa

Pump Power

9.5KW;7.5KW

Environment

Temperature -0°C-40°C,Humidity20%-80%RH

Noise Level

60db



3.Functions and structures.



a.Suction device.

b.Motor depth control.

c.Imported spare parts.

d.Security system.

e.Control panel.



4.Usage.



SIGN & ADVERTISING INDUSTRY



 BK cutting system supplies the total solution to sign & advertising industry,especially suited to registration cutting of white cardboard,sticker,acrylic,PVC,corrugated board and honey comb board, the system has improved the process flow of sign & advertising companies,accelerated production efficiency and enhanced product quality.



PACKING INDUSTRY



Common carton sample cutting machine only meets the former sample making process, while iEHCO BK carton cutting system meets small production requirement, which can cut all kinds of packaging materials easily, such as corrugated board, white cardboard, grey cardboard and PVC, maximizes the possibility of rapid completion of orders for the printing and packaging factories.



AUTOMOBILE UPHOLSTERY



BK cutting system has been applied to cutting automobile upholstery successfully, such as automobile mat, car seat, cover, sun block and car curtain.



COMPOSITES



iECHO BK cutting system replaces the traditional composites manufacturing mode, such as drawing lines and cutting yarn, especially fo the complicated allotypic patterns, it can advance at least 20 times efficiency, gurantee controllability of carbon fiber, glass fiber , aramid fiber, UHMW polyethyene etc, and reduce the labor cost greatly.









Packaging & Shipping















FAQ



1.What languages are supported?

Currently, courses are available in English. Additional languages will be added in the future. If a course in a specific language is desired, please submit your request.

2. Which power needed for the machine?

Pump:9KW with 380V voltage
Cutting machine:2KW with 220V voltage

3.What about the warranty?

12 months from the date of installation.

4.Should I prepare a computer?

You could buy the computer from us or from local market.

5.What’s the requirement of the computer?



Expansion slot: 2 PCI/PCIE slots (very important)
Operating System: WindowsXP/ Windows7 32 BIT or 64 BIT
