Home > Products > Label Making Machines > MYG 320 Model Automatic Label Hot Foil Stamping and Die Cutting Machine
MYG 320 Model Automatic Label Hot Foil Stamping and Die Cutting Machine
US$ 11,000 - 20,000
/ Set
1 Set(Min. Order)
- Ningbo/Shanghai
- T/T Credit Card
You May Like
-
WQM-320G Automatic Label Die Cutting Machines With Optional Hot Foil Stamping Device
-
DK-320G Model Label Slitter Rewinder Machine With Rotary Die Cutting
-
FP-450 Model Adhesive Label Flexo Printer
-
ZBS-320 Label Flexo Printing Machine
-
FP320 Sticker Label Printer
-
FP-450 Model Label Sticker Flexo Printing Press for Sale
Product Details
| Condition | New | Type | Other, flat die cutting machine | |
| Automatic Grade | Automatic | Place of Origin | Zhejiang, China | |
| Brand Name | Kingsun | Model Number | MYG-320 | |
| Voltage | 280V 1P | Power(W) | 4.5kw | |
| Dimension(L*W*H) | 2300 X800 X 1850 mm | Weight | 1500kg | |
| Certification | CE | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
MYG 320 Automatic Label Hot Foil Stamping and Die-cutting Machine
Features:
This machine is suitable for hot foil stamping and die cutting adhensive label,film label and hologram label ect, this machien can hot stamping and die cutting at one process.
1.Feeding system use AC servo motor
2.Use AC frequency converter
3.PID automatic thermostatical control
4.Imported holographic positioning sensor
Main technical specifications:
Stamping cutting area | 320x250mm |
Max paper width | 340mm |
Max. unwinding diameter | 500mm |
Max. rewinding diameter | 500mm |
Speed | 1200-10000stamps/H |
Fiol size | ≤Ø180 ID=25/76mm |
Position precision | ±0.15mm |
Foil feeding shaft | 2 shafts |
Main motor power | 2.2kw |
Whole machine power | 4.5kw/280V |
Overall dimensions | 2300X800X1850mm |
Weight | About 1500kg |
Contact Us
- Wenzhou Kingsun Machinery Industrial Co., Ltd.
- Contact nameMike Li Chat Now
- Phone86-577-88939966 88902233 8893
- AddressNo.1002 Heyuan Mansion, Xincheng, Wenzhou, Zhejiang
