Electrical Insulation Varnish1032-K Alkyd Coated Lacquer

Name: Electrical Insulation Varnish1032-K Alkyd Coated Lacquer
Brand: zhufeng
SKU: 144098742
Availability: InStock

Negotiable MOQ: 500 Kilograms (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Henan, China

Main Raw Material:

Other, melamine

Usage:

Electrical Insulating Varnish

Xuchang Zhufeng Insulation Materials Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Main Raw Material Other, melamine

Usage Electrical Insulating Varnish

Brand Name zhufeng

Model Number 1032-K

Specifications

Electric insulation varnish-1032-K Alkyd coated lacquer
Insulating grade :B
Temp class:130 oC
Impregnant ; 200# xylene

Class B insulation (130)

Good drying and thermal elasticity, oil resistance and higher dielectric. Used for impregnating coils of electric machines and apparatus.

Package : 15Kg180 Kg metal pail packing

Technical standard : JB/T9558-1999

Thchnical specifiction :

Item	performance	Unit	Requirment
1	Appearance		Lacquer dissolve uniformity ,no and impurity chaotic ,with smoothness lacquer
2	viscidity NO 4 cup ,under 23±2	S	40±8
3	solid content 105±2,2h	%	50±2
4	Lacquer film drying time105±2,≤2h		2Hno adhibit
5	solidify capacity		no infrrior to S1U114.2
6	acid number	MgKOH/g	≤10
7	electric intensity	MV/m	Average≥70
8	Volume resistance	Ω.m	Average≥1×1012
