Home > Construction & Decoration > Heat Insulation Material > Glass Wool > DDP Insulation Paper for Transformer
US$ 2.5 - 4
MOQ: 500 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
zhufeng
Model Number:
DDP
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Flexible Composite Material Fish Paper 6520NegotiableMOQ: 1000 Kilograms -
Quality Good 6630 DMD Used for Electrical InsulationNegotiableMOQ: 1200 Kilograms
-
6640 NMN Nomex Paper Polyimide Film Composite Insulation PaperNegotiableMOQ: 300 Kilograms
-
6521 Mylar/ Fish Kraft PaperUS$ 1.4 - 2.2MOQ: 500 Kilometers
-
6641 DMD Electrical Insulation PaperUS$ 2 - 3.5MOQ: 300 Kilograms
Place of Origin
Henan, China
Brand Name
zhufeng
Model Number
DDP
Type
Insulation Paper
Material
Composite Polymer
Application
High Voltage
Specifications
DDP insulation paper pass ISO9001 ROHSHigh quality and competitive price
quick delivery excellent service
Diamond dotted paper(DDP insulation paper)
| Diamond dotted paper(DDP) is made of insulating paper with diamond-shape epoxy resin dotted on both sides. The epoxy used in D.D.P contains a kind of incubative hardener material. It is a dry and crisp material at normal temperature. This product has good dielectric properties and good mechanical properties after heat solidification. It is to be used in oil-immersed transformers for the insulation between of coils and between layers of oil immerged power distribution transformers. Width: 800mm, 1, 000mm, 1, 050mm, 1, 200mm Thickness:0.08mm, 0.13mm, 0.18mm, 0.25mm, 0.38mm, 0.50mm |
| . It is to be used in oil-immersed transformers for the insulation between of coils aDiamond dotted paper(DDP) is made of insulating paper with diamond-shape epoxy resin dotted on both sides. The epoxy used in D.D.P contains a kind of incubative hardener material. It is a dry and crisp material at normal temperature. This product has good dielectric properties and good mechanical properties after heat solidificationnd between layers of oil immerged power distribution transformers. Width: 800mm, 1, 000mm, 1, 050mm, 1, 200mm Thickness:0.08mm, 0.13mm, 0.18mm, 0.25mm, 0.38mm, 0.50mm |
