6520 ELECTRICAL INSULATION FISH PAPER
US$ 1 - 2.2
/ Kilogram
1000 Kilograms(Min. Order)
- any port of Chinese
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | zhufeng | |
| Model Number | 0.15-0.50mm | Type | Insulation Paper | |
| Material | Other, Pressppaer with polyester film | Application | Low Voltage |
Product Description
Specifications
We are one biggest Manufacturer in insulation material .our factory established in 1995. High quality and best price waitting yo6520 Electrical insulation fish paper , 6520 PET film /paper
Features and Applications:
- Class E insulation (120)
- High mechanical strength and excellent dielectric property.
- As slot, interturn and liner insulation for E-grade motors and electric appliances.
Availability:
- Form: rolls, sheets, strips
- Colour: green, blue, brown .
Thickness:0.15mm,0.20mm,0.25mm,0.30mm,0.35mm,0.40mm,0.45mm,0.50mm
Width:1000mm
- Class E insulation (120)
- High mechanical strength and excellent dielectric property.
- As slot, interturn and liner insulation for E-grade motors and electric appliances.
Availability:
- Form: rolls, sheets, strips
- Colour: green, blue, brown .
Thickness:0.15mm,0.20mm,0.25mm,0.30mm,0.35mm,0.40mm,0.45mm,0.50mm
Width:1000mm
Standard: JB4060-91
| Product Name | Properties | Value | |||||
| 6520-28 | Thickness(mm) | 0.15 | 0.17 | 0.2 | 0.22 | 0.25 | 0.27 |
| Tolerance(mm) | ±0.020 | ±0.020 | ±0.030 | ±0.030 | ±0.030 | ±0.030 | |
| Breakdown Voltage(kv) | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | ≥6 | |
| Test method | IEC-626 | ||||||
| Colour | Brown, Blue, Gray and Green | ||||||
| Product Name | Properties | Value | |||||
| 6520-36 | Thickness(mm) | 0.15 | 0.17 | 0.2 | 0.22 | 0.25 | 0.27 |
| Tolerance(mm) | ±0.020 | ±0.020 | ±0.030 | ±0.030 | ±0.030 | ±0.030 | |
| Breakdown Voltage(kv) | ≥7 | ≥7 | ≥7 | ≥7 | ≥7 | ≥7 | |
| Test method | IEC-626 | ||||||
| Colour | Brown, Blue, Gray and Green | ||||||
| Product Name | Properties | Value | |||||
| 6520-50 | Thickness(mm) | 0.15 | 0.17 | 0.2 | 0.22 | 0.25 | 0.27 |
| Tolerance(mm) | ±0.020 | ±0.020 | ±0.030 | ±0.030 | ±0.030 | ±0.030 | |
| Breakdown Voltage(kv) | ≥8 | ≥8 | ≥8 | ≥8 | ≥8 | ≥8 | |
| Test method | IEC-626 | ||||||
| Colour | Brown, Blue, Gray and Green | ||||||
