Help CenterMini Pleat Hepa Filter
Related Products
-
G3 G4 Replacement Panel Pleated Pre FilterUS$ 1.5 - 5MOQ: 1000 Pieces -
Nonwoven Medium Efficiency Pocket Air Filter Fabric for Air Conditioning SystemUS$ 1.5 - 5MOQ: 1000 Square Meters
-
Non Woven Water Proof and Oil Proof Polyester Filter Clothes for Cement PlantUS$ 2.3 - 5MOQ: 1000 Square Meters
-
China Factory Supply 316L Stainless Steel Supporting Cage for BaghouseUS$ 6 - 8MOQ: 1000 Meters
-
Power Plant Needle Punched PPS Blended PTFE Filter Fabric for BaghouseUS$ 9.5 - 12MOQ: 1000 Square Meters
Specifications
aluminum frameMedia:glass filter fiber paper
High dust holding capacity
Long service
aluminum frame
1.Advantages
1.Mini-pleat design lowers operating costs
2.Lightweight and compact
3.Low off-gassing components
4.Wide range of efficiencies
5.Longer operating life
6.Higher flow rate
7.Low pressure drop
8.Low noise
9,Low resistance
2.Features
Frame:Anodized aluminum frame.
Media: Using special glass fiber filter paper as the filter material, high dust-holding capacity,low initial resistance.
Efficiency:(EN779:2002)H13,H14,U15
(ASHRAE 52.2:2007)MERV18,MERV19,MERV20.
Each filter is through rigorous testing.
Recommended final pressure drop:450Pa.
3.Applications
Suitable for electronics, pharmaceutical industry, hospital, and theoccasions required the high cleanliness terminal filtration.
4.Common Specifications
|
Model
|
Dimensions
|
Media Area
(m2) |
Rated Air Flow
(m3/h) |
Face Velocity
(m/s) |
Initial Pressure Drop
(Pa) |
||
H13 |
H14 |
U15 |
|||||
W×H×D (mm) | |||||||
SHW610/03-50 |
305×305×50 |
1.6 |
150 |
0.5 |
≤190 |
≤250 |
≤280 |
SHW610/05-50 |
305×610×50 |
3.3 |
300 |
||||
SHW610/10-50 |
610×610×50 |
6.7 |
600 |
||||
SHW610/15-50 |
915×610×50 |
10.1 |
900 |
||||
SHW610/20-50 |
1220×610×50 |
13.5 |
1200 |
||||
SHW610/03-70 |
305×305×70 |
2.7 |
250 |
0.75 |
|||
SHW610/05-70 |
305×610×70 |
5.5 |
500 |
||||
SHW610/10-70 |
610×610×70 |
11.3 |
1000 |
||||
SHW610/15-70 |
915×610×70 |
17.0 |
1500 |
||||
SHW610/20-70 |
1220×610×70 |
22.7 |
2000 |
||||
SHW610/03-90 |
305×305×90 |
3.7 |
320 |
1.0 |
|||
SHW610/05-90 |
305×610×90 |
7.5 |
650 |
||||
SHW610/10-90 |
610×610×90 |
15.4 |
1300 |
||||
SHW610/15-90 |
915×610×90 |
23.2 |
2000 |
||||
SHW610/20-90 |
1220×610×90 |
31.1 |
2600 |
||||
1. If you meet specifications, structural changes, the company provides the newest data shall prevail
2.We accept the orders of non-standard specifications
