Home > Packaging & Printing > Packing Machinery > Sealing Machine > Automatic Horizontal Band Heat Sealer BD+7

Automatic Horizontal Band Heat Sealer BD+7

Automatic Horizontal Band Heat Sealer BD+7 photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Film
Junko Fze
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type Film
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage AC220V
Power 1000W
Brand Name Newlong
Model Number BD+7
Dimension(L*W*H) 885 x 511 x 885
Weight 60kg
After-sales Service Provided No overseas service provided
Product Description


Product Application:

Automatic Heat Sealer BD+7 is a suitable bag sealing machinery for small bags and sacks made of polyethylene or vinyl coated papers. For this horizontal band sealer, the heat seal is fused by applying pressure through a series of compression rollers; immediately cooled by a “cool air” blower system. It promotes a cost effective and potential output.



SPECIFICATIONS FOR AUTOMATIC HORIZONTAL BAND HEAT SEALER
Machine Model
BD+7
Seal Width
8 mm
Speed (m/min.)
0~12 (50 Hz)
Conveyor Length
855 mm
Conveyor Width
200 mm
Conveyor Adjustment
50mm (below sealing line)
Sealing Height (3 steps)
740mm, 780mm, 820mm (from floor level)
Conveyor Extension
60mm (horizontally)
Incline
15 degrees from horizontal position
Temperature Control
0 - 300° C
Heater
450 W x 2 pcs.
Drive Motor
40 Watts
Electrical Consumption
1kW, 1 Phase, 50/50 Hz
Net Weight
Approximately 60 Kg.
Machine Dimensions
885mm x 511mm x 995mm
Bag Width
Band Seal

Main Features:


1) Speed controller and digital temperature controller are equipped.

2) Gusset roller is attached as standard

3) The conveyor moves 60 mm horizontally toward operator.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.
