Glass Microsphere

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Shape:

Curve

Structure:

Solid

Shanghai Zdan International Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Shape Curve

Structure Solid

Type Other, Glass microsphere

Specifications

Glass microsphere

Glass microsphere

Serial Properties Table of Gray white Hollow Microspheres
Type	Color	Partide size μm	Volume wt.g/cm³	Use	Properties
K-800	Gray white	600~1200	0.3~0.45	o be filled in printing ink, adhesive, engineering plastic, modification rubber, electrical appliance insula- ting commponents,seal components	increasing filler fluidity. low oil absorption and shrinkage. good stability and weather-resistance. excellent electrical insulating properties and low price
K-600	Gray white	200~600	0.3~0.45
K-180	Gray white	10~180	0.3~0.45
K-100	Gray white	10~125	0.3~0.45

Serial Properties Table of Silver-clad Microspheres
Type No	Color	Particle size μm	Volume wt.g/cm³	Use	Properties
Silver-clad	Dim gray	10~60	0.45~0.6	Filling in conductive adhesive. Conductive Printing ink. Conductive rubber	good conductive fillers. Same effect as silver powder. The price is one third of the silver powders
Hollow mi-
crospheres

Silver-clad	Dim gray	10~60	1.4~1.8
solid
micro-
spheres

Serial Properties Table of Solid Microspheres
Type	Color	Particle size μm	Volume wt.g/cm³	Use	Properties
0	Gray white	10~50	1.6~1.8	filling in adhesive.plastic rubber, abrasive ground blast derusing.art lamp and reflective mark line	high roundness rate.good hardness.fine stability and direct reflection
1	Gray white	50~85	1.6~1.8
2	white	65~90	1.6~1.8
3	white	80~105	1.6~1.8
4	white	105~120	1.5~1.8
5	white	120~150	1.5~1.8

Serial Properties Table of Silver-clad Microspheres
Type No	Color	Particle size μm	Volume wt.g/cm³	Use	Properties
Silver-clad	Dim gray	10~60	0.45~0.6	Filling in conductive adhesive. Conductive Printing ink. Conductive rubber	good conductive fillers. Same effect as silver powder. The price is one third of the silver powders
Hollow mi-
crospheres

Silver-clad	Dim gray	10~60	1.4~1.8
solid
micro-
spheres
