hot melt glue granule making machine

Specifications

hot melt glue granule making machine
1,application:hot melt glue stick,granule
2,capacity:80-130kg/hour



hot melt glue granule making machine



           --- Customize









Product Introduction:



1. The line can produce various type of hot melt adhesive sticks
2. Hot melt adhesive sticks applies to handicraft,electrical appliances,clothing,toys and so on
3. The device doesn’t need reactor,it not only saves equipment,but also improves the product quality
4. It can continuous production, overcomes the disadvantage of mixing uneven and poor transparency of reactor
5. Save energy
6. One-step of reaction and extrusion to produce
7. The screw of the main machine by special design
8. Good mixed , smooth surface, good diaphaneity, uniform specifications
9. It is the most advanced technology of producing hot melt adhesive stick.
10.  Provide production formula and go to the buyer’s country to install and trial run the machine after buying the machine











2.  Due to high temperature to thrust bearing grease filling moC2 (variable) should always check, and a crate when added new gearoil to ensure the normal operation of machine with the using life



 3.  Mixing materials, processing in cold mix should pay attention: raw material should be clean, without sundry, defend metal, sand, small tools and other sundry raw materials, mixing with the name, influence the quality of the products, the production equipment is found in the process of inspection and repair of abnormal should stop



 4.  Traction cooling unit



  In the production of rubber bar from entering traction stage, drawer shall be transferred to amount to squeeze, to ensure the glue stick synchronization, often should for filling in the engine cooling water pump, sew to check, cooling water to replace frequently maintain clean. Electrical no extremes of case motor disorders























Project name	Unit	Model
Screw diameter	mm	90
Lenth-diameter radio	LD	321
Rod thickness	MM	8--20
Extrusion quantity	Bar	2
Output	Kgh	80-110
Moter power	KW	18.5
Firstly assist power	KW	1.5
Secondly assist power	KW	1.5
Heating power	KW	23
Dimension(lenth*width*hhight)	m	28*2*2.6













 Company Information:



Laizhou Yuanda Chemical Industry Machinery Co., Ltd is located in the beautiful and fertile Bohai Bay which is the hub of Yantai, Qingdao and Weifang.By virtue of convenient and good location, it is a perfect place for trade business.



The company integrates scientific research, development, production,sales and after-sales service. It owns a group of specialists having rich experience in machinery designing, developing and management.Based on reasonable structure,good durability and easy operation,etc.



Our factory can manufacture a lot of chemical ang industry machines,like: reactor, disperser, mixer, sand mill, colloid mill, SMC sheet machine, resin production line, paint production line, hot melt glue production line, floral foam production line, etc.



 Pictures:

    pictures:





























other machine list





grinding machine,mixing machine,reactor,SMC machine

resin complete production line,coating production line,floral foam production line,adhesive production line.





Here we produce this polyester resin making machines from 50L lab small plant to 10tons mass production lines,

we have already successfully sent our engineers to help with installation in Saudi Arabia, Thailand, Iran, etc,



If any interest, pls contact:
