chemical reactor/kettle/ mixing tank/autoclave price
- 400 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Mixer Type: | Agitator | Product Type: | Cosmetic |
Application: | Liquid with Suspended Solids | Additional Capabilities: | Drying | Place of Origin: | Shandong, China |
Brand Name: | YD | Model Number: | YD | Max. Loading Capacity: | 5000L |
Voltage: | Customized | Power(W): | customized | Dimension(L*W*H): | Custom Made |
Certification: | ISO9001 | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Chemical Reactor/Kettle/ Mixing Tank/Autoclave Price
Agitator
Blade agitator, frame agitator, disperser, homogenizer, anchor agitator
Specification
Mixer type: homogenize, frame, anchor, axis
Material Quality: SUS304 or 316L
Appearance: mirror polished
Different size for your selection: 100L-6000L according to your need
Layer: three layer, two jacket. inner vessel, jacket and insulation with the configurations of agitator, CIP hole, Manhole, sight glass, thermometer
Type of Heating: Electric heating, steam heating, oil circulation heating, outside (inside) coil heating
Faction: Mixer, heating and keep warm, cooling, disperser, vacuum, homogenizer, lifting, sealing
Applications
This stainless steel chemical reactor for paint, emulsion, adhesive, petroleum, chemical, rubber, pesticide, dye, medicine and food industry. Used to achieve curing, hydrogenation, alkylation, polymerization, condensation process.
Food procession, cosmetics production, chemical industry, dyeing and printing facilities, essence and fragrant substance production, fine chemical industry, emulsification of diesel oil and pitch.
Configurations
1.It is sealed type, and the material contacting the liquid is the stainless steel 304 or 316L
2.One set of totally enclosed blending plant
3.A self-rotating type cleaning
4.A set of air respirator, matching a 0.28pam folding filter element.
5.A set of liquid meter
6.A 0-100 thermometer
7.Manhole 450mm
8 A 100mm sight glass
9 A 036V light
Main Technical Parameters:
Packaging Details: Usually Package By Three Plywood,Suitable And Convenient For Shipment
Delivery Detail: About 15-30 Days After Receive Deposit
After-sales service
After-sales service process will start once our clients receive the goods. YuanDa had established &standardized the aftersales service management system. In addition, YuanDa also efficiently supervise and manage the whole after-sales service system.
Warrantly
The warranty is one year. Since clients confirm they received the goods, we’ll provided free replacement spare parts for the damaged components (except the damages caused by wrong operation) , which we’ll deliver through FedEX,UPS, by air, by sea.
Maintainance
Lifelong maintenance.YuanDa provides English operation manual to instruct how t o install& maintain. If client have any technical question, we will provide instruction by phone, email, etc. timely.
Installation
YuanDa provides you with the overall installation of complicated machines, or customized equipment, or complete production line. After installation, we will make inspection of the whole machine, operate equipment, and provide you with testing reports of installation.
Training
Our client can install the machine according to manual book provided by YuanDa, or before delivery, customers can come to YuanDa factory and have training how to operate and maintain the equipment, or our engineer is available to instruct in on-site
We are the professional manufacturer for chemical machine, we have do this machine manufature more than 20 years,have rich experience and mature technical design and export this machine.
Depend on rich experience and advance technical, we export machine to USA, UAE, Russia, Italy, Armenia, Saudi Arabia, Pakistan, India, Indonesia, Brazil, Iran, etc.
The chemical and industry machine we can provide like:
SMC production line, BMC production line, resin production line, coating production line, adhesive production line, floral foam production line.Reactor, ZArm mixer, dispersing machine, horizontal mixer, conical mixer, colloid mill, three roller mill, ball mill, sand mill.
WELCOME TO OUR COMPANY ANY TIME
About Delivery time
Q-----What’s the delivery term for making business with us?
A--Usually we send the shipment in FOB term.However, the terms of CIF are acceptable which depend on the preference of clients.
About Lead Time
Q------What’s the lead time after placing the order?
A------Usually it takes about 15~30 days after we received your confirmation.
However, it would depend on our production line schedule(the timing clients place order)and the complication of the item.
About Payment Term
Q------What’s the Payment Term?
A------By T/T in Advance, or Irrevocable L/C as Sight.
We will offer you price referring to your detail request, so please kindly inform us of the material, viscosity, density, etc, and other
requirements you prefer, and the special offer will be given.
The pictures are above just for your reference.
Our machines can be customized, leave an inquiry to know more details about price, packing, shipping
and price.Any questions, feel free to contact with this supplier: Ada Lee
