new 2016 rotary evaporator electric reactor
USD $2,300 - $26,000
/ Unit
1 Unit(Min.Order)
- 1 Unit / Units per Month
- QINGDAO
- T/T
You May Like
-
customized stainless steel Jacketed emulsion blender Kettle/glass lined reactor price/enamel reactor
-
Hot melt glue/PVAC/EPS resin chemical heating industrial reactor
-
liquid chemical agitator mixer tank
-
stainless steel vertical liquid stirrer mixer(50L-10000L)
-
high quality liquid agitated mixer tank
-
hot sale stainless storage tank
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | YD | Model Number | YD-FY |
Product Description
Electric heating reactor is in absorbs domestic and international advanced technique developed on the basis of the new product, widely used in pharmaceutical, building materials, chemical, paint, resin, food industry etc, with rapid heating, high temperature resistance, corrosion resistance, health, no pollution, no boiler heating, convenient use, etc
Technical parameters
model | nominal capacity L | Actual capacity L | Heating powerKW*strip | Oil clip of capacityL | Inner pot size Dmm | Jacket size D1mm | Bearing screw holes center D2mm | Stirring speed | Weight kg |
50L | 50 | 78 | 2*4 | 96 | Ø400 | Ø600 | Ø828 | 85 | 4-25 |
100L | 100 | 127 | 2*6 | 127 | Ø500 | Ø700 | Ø928 | 85 | 4-25 |
300L | 300 | 327 | 4*6 | 218 | Ø800 | Ø1000 | Ø1148 | 85 | 4-25 |
500L | 500 | 509 | 4*9 | 269 | Ø900 | Ø1100 | Ø1252 | 85 | 4-25 |
1000L | 1000 | 1017 | 4*12 | 400 | Ø1200 | Ø1400 | Ø1588 | 85 | 4-30 |
2000L | 2000 | 2154 | 4*15 | 850 | Ø1400 | Ø1600 | Ø1840 | 85 | 4-30 |
3000L | 3000 | 3201 | 5*15 | 1015 | Ø1600 | Ø1750 | Ø2040 | 85 | 4-35 |
4000L | 4000 | 4020 | 5*15 | 1226 | Ø1600 | Ø1750 | Ø2070 | 85 | 4-36 |
5000L | 5000 | 5170 | 5*18 | 1400 | Ø1800 | Ø2000 | Ø2320 | 85 | 4-36 |
Best Regards
Elaine
Contact Us
- Laizhou Yuanda Chemical Industry Machinery Factory
- Contact nameXiaobin Liu Chat Now
- Phone86-535-2357998
- AddressXisungezhuang Village, Shahe Town, Laizhou
