30L/batch Slicone Mixer

30L/batch Slicone Mixer thumbnail-1
30L/batch Slicone Mixer photo-1
US$ 5,700 - 13,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mixer Type:
Other, Z Blade
Product Type:
Other, Rubber,Chewing gum,Dough,Silicone sealant
Contact Supplier Request Quote Chat Now
Laizhou Yuanda Chemical Industry Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Mixer Type Other, Z Blade
Product Type Other, Rubber,Chewing gum,Dough,Silicone sealant
Application Other, High viscous material
Additional Capabilities Other, Heating,kneading,mixing
Place of Origin Shandong, China
Brand Name YD
Model Number YD-NH
Max. Loading Capacity 5000L
Voltage Optional
Certification Euro CE
Warranty 1 year after shipped
After-sales Service Provided Engineers available to service machinery overseas

Specifications

silicone mixer,
quick kneading plastic,rubber,sealant,chewing gum;
2-5000L kneading capacity.

30L/batch Silicone Mixer



Application:



1. Food industry: chewing gum, dough.

2. Chemical industry: Silicone Sealant, Glass Cement, Butyl, Rubber, Hot-melt Glue, BMC, DMC, Plastics, Printing Inks, etc.

Features:



1. Double Z Arm.     One quicker, another slower.      ---Quick Mixer and Kneader.

2. Difderent mixture discharging ways: Hydraulic tilt discharge, Screw extruding, Ball valve discharge.

3. Jacket for heating/ cooling;     Or single layer.

4. Material: 304 stainless steel, 316ss, carbon steel.

5. Vacuum available.



Model NH-50 NH-100 NH-300
Capacity 50L 100L 300L
Useful volume (60% of total) 30L 60L 180L
Motor power 3KW 7.5KW 15KW
Speed

Quick arm: 45r/min

Slow arm: 23r/min

Q:35r/min

S:22r/min

Q:37r/min

S:21r/min
Jacket heating 4KW 4KW 9KW
Vacuum type -0.094MPA
Pressure type 0.45MPA
Shape dimension (L*W*H) 1.2*1.1*0.5M 1.7*1.6*0.8M 1.8*0.8*1.4M
Weight 560Kgs 1250Kgs 1800Kgs
Delivery time 40 days after payment

 30L/batch slicone mixer

30L/batch slicone mixer

30L/batch slicone mixer

30L/batch slicone mixer



We offer this mixer capacity for 2L-3000L.

                                                            (useful capacity is 60% of total.)





Welcome contact us for more details,





Ms. Anna Miller/ Sales Manager   +86-15092424957



Laizhou Yuanda Chemical Industry Machinery Factory (solid factory)
